Каталог запасных частей к технике: LiuGong CLG-626R. 22Y0023 Rear Frame Assembly
1
2
3
4
4
5
5
6
6
7
8
9
10
18
20
22
26
27
28
29
31
32
47
48
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 30X0021 | Frame | |
| 2 | 47W0051 | Viewfinder | |
| 3 | 41X0016 | Bar | |
| 4 | 00В0035 | Болт | |
| 5 | 06В0007 | Шайба | |
| 6 | 06В0008 | Шайба | |
| 7 | 12U0065 | Cover plate | |
| 8 | 81U0014 | Washer | |
| 9 | 41Х0017 | Bar | |
| 10 | 41X0018 | Bar | |
| 11 | 17W0004 | Rear cover plate | |
| 12 | 17W0003 | Cover plate | |
| 13 | 11U0127 | Cover plate | |
| 14 | 00D1796 | Rib | |
| 15 | 17W0002 | Cover plate | |
| 16 | 36D0371 | Cover plate | |
| 17 | 11А2305 | Cover plate | |
| 18 | 72U0018 | Bob-Weight I | |
| 19 | 11А2301 | Plate | |
| 20 | 72U0019 | Bob-Weight II | |
| 21 | 11U0125 | Plate | |
| 22 | 13U0302 | Cover plate | |
| 23 | 17W0005 | Cover plate | |
| 24 | 11В0075 | Bolt | |
| 25 | 06В0006 | Шайба | |
| 26 | 21А2559 | Nip | |
| 27 | 00В0020 | Болт | |
| 28 | 03V0532 | O-ring | |
| 29 | 06В0054 | Шайба | |
| 30 | 36D0322 | Cover plate | |
| 31 | 60U0020 | Pin | |
| 32 | 08В0041 | Pin | |
| 33 | 10А2096 | Cover plate | |
| 34 | 17W0006 | Cover plate | |
| 35 | 11U0124 | Plate | |
| 36 | 53U0049 | Cover | |
| 37 | 80U0002 | Washer | |
| 38 | 04X0046 | Diesel tank | |
| 39 | 16W0008 | Cover Asm | |
| 40 | 12V0441 | O Ring | |
| 41 | 00В0085 | Болт | |
| 42 | 06В0005 | Шайба | |
| 43 | 04U0006 | Cover plate | |
| 44 | 12В0246 | Кольцо круглого сечения | |
| 45 | 36X0002 | Flange Cover | |
| 46 | 11U0120 | Cover plate | |
| 47 | 72U0020 | Bob-Weight III | |
| 48 | 72U0021 | Bob-Weight IV | |
| 49 | 48С0435 | Cover plate |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
