Каталог запасных частей к технике: LiuGong CLG 425. 11Y0071 002 HYDRAULIC SYSTEM
1
2
3
4
4
5
6
7
8
8
8
9
9
10
10
11
12
13
14
15
15
16
16
16
17
17
17
18
19
20
20
21
21
22
23
23
24
24
25
25
26
26
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
49
50
50
51
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
67
68
68
69
69
70
71
74
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 12C3175 | Hydraulic lock | |
| 2 | 06C8966 | Hose | |
| 3 | 09C0639 | Jacket | |
| 4 | 09C0202 | Clamp | |
| 5 | 44C1634 | Hydraulic lock | |
| 6 | 10C1679 | Blade swing cylinder | |
| 7 | 10C1678 | Blade lift cylinder | |
| 8 | 30C0164 | Connector | |
| 9 | 09C0207 | Clamp | |
| 10 | 09C0204 | Clamp | |
| 11 | 12C0547 | Work valve mounting-lh | |
| 12 | 47C0551 | Platform as | |
| 13 | 06C1316 | Hose | |
| 14 | 06C0966 | Hose | |
| 15 | 09C0126 | Хомут двойной | |
| 16 | 00B0005 | BOLT | |
| 17 | 06B0002 | Шайба | |
| 18 | 21C0129 | Hydraulic oil tank | |
| 19 | 00C3181 | Pump oil suction lines | |
| 20 | 10C1871 | Hitch steer cylinder | |
| 21 | 06C7258 | Hose | |
| 22 | 44C1599 | Swivel joint | |
| 23 | 06C9265 | Hose | |
| 24 | 06C3128 | Hose | |
| 25 | 03B0053 | NUT | |
| 26 | 09C0380 | Clamp | |
| 27 | 06C7529 | Hose | |
| 28 | 06C9316 | Hose | |
| 29 | 06C9317 | Hose | |
| 30 | 06C2875 | Hose | |
| 31 | 06A1858 | Mounting plate | |
| 32 | 06C7533 | Hose | |
| 33 | 06C9315 | Hose | |
| 34 | 11C0482 | Swing motor as | |
| 35 | 44C0099 | Pipe as | |
| 36 | 44C1829 | Pump as | |
| 37 | 05C3746 | Hose | |
| 38 | 06C9266 | Hose | |
| 39 | 06C9267 | Hose | |
| 40 | 07C2707 | Hose | |
| 41 | 06C9889 | Hose | |
| 42 | 12C0548 | Work valve mounting-rh | |
| 43 | 31C0145 | Connector | |
| 44 | 10D8614 | Tube as | |
| 45 | 09C1204 | Clamp | |
| 46 | 10C1873 | Blade pitch cylinder | |
| 47 | 06C7535 | Hose | |
| 48 | 06C9319 | Hose | |
| 49 | 03B0021 | NUT | |
| 50 | 06B0006 | Шайба | |
| 51 | 00B0020 | BOLT | |
| 52 | 82A1229 | Guard | |
| 53 | 83A0182 | Grommet | |
| 54 | 19A2734 | Clamp | |
| 55 | 06C2130 | Hose | |
| 56 | 06C8977 | Hose | |
| 57 | 10C1872 | Front wheel tilt cylinder | |
| 58 | 10C1874 | Blade pitch cylinder | |
| 59 | 06C9318 | Hose | |
| 60 | 10C1875 | Blade sideshift cylinder | |
| 61 | 09C1430 | Clamp | |
| 62 | 15C0230 | Accumulator mounting as | |
| 63 | 06C0971 | Hose | |
| 64 | 02A0281 | Tee | |
| 65 | 06C1593 | Hose | |
| 66 | 06C3472 | Hose | |
| 67 | 06C7531 | Hose | |
| 68 | 00B0056 | Болт | |
| 69 | 06B0001 | WASHER | |
| 70 | 12C3181 | Hydraulic lock | |
| 71 | 12C3180 | Hydraulic lock | |
| 72 | 37B0004 | Хомут | |
| 73 | 37B0010 | Соединения блокировочного кабеля | |
| 74 | 06C7532 | Hose |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
