Каталог запасных частей к технике: LiuGong CLG 425. 04E0114 003 WORM BOX
1
2
3
4
4
5
5
6
6
7
10
11
11
12
13
14
15
16
17
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
36
37
38
39
40
41
41
42
43
44
45
46
47
48
49
50
51
52
53
54
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 70A0661 | Housing | |
| 2 | 01B0188 | BOLT | |
| 3 | 06B0226 | Шайба | |
| 4 | 03B0743 | Plug | |
| 5 | 06B0053 | WASHER | |
| 6 | 00B0190 | BOLT | |
| 7 | 06B0237 | WASHER | |
| 10 | 04B0078 | Болт | |
| 11 | 06B0006 | Шайба | |
| 12 | 01B0507 | BOLT | |
| 13 | 06B0220 | Шайба | |
| 14 | 00B0085 | Болт | |
| 15 | 53A0607 | Cover | |
| 16 | 12B0005 | Кольцо круглого сечения | |
| 17 | 23B0123 | Tap.roller brg | |
| 18 | 45A0011 | Worm | |
| 19 | 12B0375 | Кольцо круглого сечения | |
| 20 | 56A0507 | Shim | |
| 21 | 53A0604 | Bearing support | |
| 22 | 55A1742 | Sleeve | |
| 23 | 08B0225 | Pin | |
| 24 | 05B0129 | Stud | |
| 25 | 06B0015 | Шайба | |
| 26 | 03B0103 | Гайка | |
| 27 | 53A1445 | Cover | |
| 28 | 56A0512 | Snap ring | |
| 29 | 28C0097 | Shim | |
| 30 | 12B0176 | O-RING | |
| 31 | 55A3257 | Bushing | |
| 32 | 55A4280 | Steel sleeve | |
| 33 | 75A0297 | Disk spring | |
| 34 | 12B0971 | O-ring | |
| 35 | 53A1079 | Cover | |
| 36 | 52A0346 | Disc | |
| 37 | 37C0866 | Friction plate | |
| 38 | 52A0860 | Steel plate | |
| 39 | 45A0010 | Worm gear | |
| 40 | 56A0511 | Copper washer | |
| 41 | 55A4521 | Bushing | |
| 42 | 62A0429 | Spline shaft | |
| 43 | 13B0528 | Floating seal | |
| 44 | 56A1992 | Washer | |
| 45 | 12B0832 | O-ring | |
| 46 | 52C0218 | Gear | |
| 47 | 55A4519 | Bushing | |
| 48 | 03B1457 | Nut | |
| 49 | 08B0100 | Pin | |
| 50 | 06B0024 | WASHER | |
| 51 | 12B0241 | O-RING | |
| 52 | 88A0111 | Sponge | |
| 53 | 53A0122 | Cap | |
| 54 | 02B0028 | Bolt |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
