Каталог запасных частей к технике: LiuGong CLG-4215. 03Е0070-001-00 PUMP DRIVE SHAFT

Тип техники Не выбрано Легковые автомобили Грузовые автомобили и прицепы Автобусы Сельхозтехника Спецтехника Двигатели Мототехника

Марка Не выбрано Ammann BOMAG CARMIX CASE IH Changlin ChengGong Dimex Doosan DYNAPAC Foton HAMM Hidromek Hitachi Hyundai JCB JLG John Deere Komatsu LIEBHERR LiuGong Lonking (LongGong) Luneng MANITOU Mitsuber New Holland PENGPU RM-Terex SANY SDLG SEM Shantui Shehwa HBXG Soosan TIGARBO VOGELE Volvo WAY WIRTGEN XCMG XGMA Xiamen YTO Yuchai Zoomlion Автокран АЗСМ Алтайлесмаш Амкодор АОМЗ Атек АТЗ Балканкар Рекорд БелАЗ Беловеж Борекс Брянский Арсенал Булат ВЭКС ГАЗ Геомаш Гидромаш Донекс Дормаш Дормашина Дорэлектромаш ДЭЗ ЕлАЗ ЗЗГТ Ижнефтемаш Канаш-электрокар КЗКТ ККЗ Клевер Клинцовский автокрановый завод КМЗ КМЗ 1 Мая Ковровец Коммаш Кранэкс КЭЗ КЭМЗ ЛЗА МАЗ МЗИК МЗКМ МЗКТ Михневский РМЗ МоАЗ Мозырский МЗ МТЗ ОЗП Онежец ПАО "ТЗА" ППС Детва Промтрактор ПТЗ Раскат СпецАгрегат ТВЭКС ТТМ УВЗ Угличмаш УЗТМ ХТЗ ЧЗКМ ЧСДМ ЧТЗ ЭКСКО ЭКСМАШ ЮрМаш

Модель Не выбрано CLG 425 (2010) CLG 777A-S (2010) CLG-2040H (2045H, 2050HL, 2040H, 2045H, 2050HL) (2016) CLG-220 (2008) CLG-225 (2008) CLG-365A (2012) CLG-375 (2008) CLG-375A (2008) CLG-385A (2008) CLG-4165 (2015) CLG-418 (2008) CLG-4215 (2010) CLG-612 (2008) CLG-614 (2010) CLG-618 (2010) CLG-626R CLG-766 (2015) CLG-766A (2012) CLG-816G (2012) CLG-835 CLG-835 (2015) CLG-835H (2015) CLG-836 (2015) CLG-842 CLG-842 CLG-842 (2015) CLG-855N (2015) CLG-856 (2015) CLG-856H (2015) CLG-856I CLG-862 (2015) CLG-877 (2015) CLG-888 (2015) CLG-904С (2007) CLG-915D CLG-915D CLG-920D CLG-920E (2015) CLG-922D CLG-922LC CLG-922LC (2008) CLG-925 (2015) CLG-925D (2015) CLG-933E (2010) CLG-B160 (2010)

Схема > Не выбрано 00E0775-005-00 FUEL TANK AS 16C0004-001-00 BREATHER CAP 16C0091-000-00 TANK COVER AS 00Y0184-001-00 COOLING SYSTEM 00Y0192-002-00 INTAKE AND EXHAUST SYSTEM 00Y0271-000-00 ENGINE SYSTEM 00Y0530-000-00 COOLING SYSTEM 00С4221-000-00 RIPPER LINES 10С0693-005-00 RIPPER CYLINDER 24C0252-000-00 LINKAGE AS 00С4933-000-00 DOZER LINES 10C0721-007-00 DOZER CYLINDER 12С1556-000-00 HYDRAULIC LOCK 00С4941-000-00 SCARIFIER LINES 10С2577-000-00 SCARIFIER CYLINDER 12С3946-000-00 HYDRAULIC LOCK 10Е0221-000-00 STEERING HYDRAULIC SYSTEM 10С1681-000-00 FRONT WHEEL STEERING CYLINDER 10С0681-006-00 FRONT STEERING CYLINDER 24С0373-000-00 BALL JOINT AS 12С0320-000-00 PRIORITY VALVE MOUNTING 44С0158-001-00 STEERING COLUMN AS 10Y0093-000-00 STEERING HYDRAULIC SYSTEM 11Е1193-000-02 HYDRAULIC SYSTEM 00с2661-000-00 PUMP OIL SUCTION LINES 10С0663-004-00 FRONT WHEEL TILT CYLINDER 10С0668-005-00 BLADE PITCH CYLINDER 10C00669-005-00 BLADE PITCH CYLINDER 10C0694-004-00 BLADE SIDESHIFT CYLINDER 10С0695-007-00 BLADE LIFT CYLINDER 10С0696-007-00 BLADE SWING CYLINDER 10C1066-003-00 STEERING CYLINDER 11С0243-000-00 PUMP MOUNTING 11С0783-000-00 SWING MOTOR 12С2800-000-00 HYDRAULIC LOCK 12С3175-001-00 HYDRAULIC LOCK 21С0129-004-00 HYDRAULIC OIL TANK 44С0099-001-00 PIPE AS 44C1599-001-00 SWIVEL JOINT 33С0028-000-00 SWIVEL JOINT 44С1604-002-00 CONTROL VALVE AS 44С1605-002-00 CONTROL VALVE AS 44С1633-001-00 HYDRAULIC LOCK 44С1634-001-00 HYDRAULIC LOCK 44С1829-000-00 PUMP AS 47С1637-000-00 PLATFORM 11Е1193-005-00 HYDRAULIC SYSTEM 11Y0384-000-00 WORK HYDRAULIC SYSTEM 11Y0384-000-01 WORK HYDRAULIC SYSTEM 13Y0113-000-00 TRAVEL HYDRAULIC SYSTEM 12С3198-002-00 CHECK VALVE AS 15Y0227-000-00 HYDRAULIC COOLING SYSTEM 11С0344-002-00 PUMP GP 11С1749-000-00 MOTOR 12С4083-000-00 SAFETY VALVE 12С0012-000-00 Safety valve NULL 15Y0514-000-00 HYDRAULIC COOLING SYSTEM 15Y0599-000-00 HYDRAULIC COOLING SYSTEM 11С0480-000-00 Radiator mounting NULL 15Y1067-000-00 HYDRAULIC COOLING SYSTEM 11С1165-000-00 MOTOR 12С2803-000-00 SWITCHING VALVE AS 12С4181-000-00 RELIEF VALVE MOUNTING 01Е0116-006-00 REAR AXLE AS 01С0226-003-00 LINE GP 01C0228-002-00 PIPING 01С0227-003-00 LINE GP 01C0229-002-00 PIPING 01С0262-002-00 LINE GP 01C0264-001-00 PIPING 01С0263-002-00 LINE GP 01C0265-001-00 PIPING 01С1155-000-00 PIPING GP 01С1156-000-00 PIPING GP 41С0479-001-00 REAR AXLE SP105550-000-00 BRAKE AS SP109936-000-00 REDUCTOR AS SP123702-000-00 MAIN REDUCER 01E0117-001-00 TYRE AND RIM AS 01Е0366 002 00 TYRE AND RIM AS 01Е0371-001-00 TYRE AND RIM AS 01Y0077-002-00 FRONT AXLE 24С0144-003-00 WHEEL LEAN LINKAGE AS 24С2504-000-00 STEERING LINKAGE 24С2308-000-00 ARTICULATED HITCH 24С2309-000-00 ARTICULATED HITCH 24D0136-002-00 LEAN-JOINT 34С2172-001-00 FRONT WHEEL HUB 01Y0096-001-00 TYRE AND RIM AS 01Y0097 001 00 TYRE AND RIM AS 01Y0175-000-00 FRONT AXLE AS 01Y0185-000-00 TYRE AND RIM AS 01Y0277-001-00 REAR AXLE AS 03Е0059-001-00 REAR DRIVE SHAFT 03Е0070-001-00 PUMP DRIVE SHAFT 22С0080-000-00 BASE AS 22С1606-003-00 BRACKET AS 03Y0051-000-00 DRIVE SHAFT MOUNTING 05Y0094 000 00 GEARBOX AND TORQUE CONVERTER AS 30С1871-000-00 CONNECTOR 30C1872-000-00 CONNECTOR 52C0065-000-00 FILLER TUBE 63C0001-000-00 FILLER CAP 20E0189-002-00 BRAKE SYSTEM 15C0106-000-00 BRAKE ACCUMULATOR MOUNTING 15C0135-002-00 SERVICE BRAKE ACCUMULATOR GP 15C0143-000-00 FILTER AS 53C0155-000-00 FILTER 45C0098-001-00 BRAKE VALVE AS 32C0122-000-00 TEE 45C0099-001-00 CHARGE VALVE AS 45C0161-002-00 BRAKE VALVE AS 20Y0176-000-00 BRAKE SYSTEM 45C0650-000-00 ACCUMULATOR MOUNTING AS 08Y0091-000-00 REAR FRAME AS 30D1847-000-00 REAR FRAME 08Y0305-000-00 REAR FRAME AS 08Y0456-000-00 FRONT FRAME AS 22C1557-000-00 SWING ARM AS 34C0317-000-00 FORK AS 08Y0475-000-00 FRONT FRAME AS 08Y0585-000-00 REAR FRAME AS 30E0934-004-00 FRONT FRAME AS 30Y0057-000-00 FRONT FRAME AS 30Y0061-001-00 ARTICULATED HITCH 32Е0149-008-00 RIPPER 32Е0161-007-00 BLADE 32E1669-001-00 WORK IMPLEMENT SYSTEM 04Е0057-013-00 WORM BOX 04Е0057-013-01 WORM BOX 43С0977-004-00 BLADE AS 43С3489-004-00 EQUIPMENT-SKEL 43С3489-004-01 EQUIPMENT-SKEL 48С2073-000-00 DUST COVER 32Y0146-001-00 WORK IMPLEMENT SYSTEM 32Y0145-002-00 WORK IMPLEMENT 32Y0145-002-01 WORK IMPLEMENT 43С3017-001-00 BLADE AS 32Y0538-000-00 SCARIFIER 32Y0691-000-00 WORK IMPLEMENT SYSTEM 04Е0103-005-00 WORM BOX 43С6043-000-00 BLADE AS 45Е1521-003-00 COUNTERWEIGHT 27С0491-000-00 COUNTERWEIGHT 45Е1554-001-00 FRONT COUNTER-WEIGHT 45Y0027-001-00 COUNTERWEIGHT 41E0548-007-00 CAB 27С0593-000-00 COVER 41E0549-000-00 REARVIEW MIRROR 47С0231-004-00 CONTROL BOX 47С0425 000 00 WATER-FREE WASHER 47C1915-000-00 DOOR-LH 47С1916-000-00 DOOR-RH 47С2351-000-00 CONTROL BOX AS 41Y0301-000-01 CAB AS 47С2903-000-00 CONTROL BOX AS 41Y0303 000 00 CAB AS 41Y0333-000-00 CAB AS 47С0535-000-00 FIRE EXTINGUISHER 46Е0021-000-00 SEAT 43Е0231-000-00 LADDER 44Y0106-002-00 ENGINE HOOD AS 48C0353-001-00 PLATE AS 22Y0254-000-00 ELECTRICAL SYSTEM 46С1258-000-00 SOUND WIRING 46С1257-000-00 RADIO/CASSETTE PLAYER 46C3902-000-00 WIPER SYSTEM 46С4012-000-00 CAB WIRING 46С7844-000-00 CONTROL BOX 46С8272-000-00 COMBINATION INDICATOR 46С7190-000-00 WIPER SYSTEM 46С7222-000-00 WORK LIGHT WIRING 46С7532-000-00 BATTERY WIRING 46С9005-000-00 REAR FRAME WIRING 46С9006-001-00 LIGHT GROUP 46C9007-000-00 CAB WIRING 46C9008-000-00 FRONT FRAME WIRING 49С2085-000-00 BATTERY WIRING 46С7457-000-00 REAR FRAME WIRING 46C9404-000-00 CAB WIRING 49С0093-000-00 FRONT FRAME WIRING 49С1373-000-00 WORK LIGHT WIRING 49C1399-000-00 CAB WIRING 49C0612-000-00 WIPER GP 49С2290-000-00 FAN 46С1787-003-00 FAN AS 49С2490-000-00 ROTATING BEACON WIRING AS 49C2890-000-00 AUX CONTROL WIRING 23Y0039-003-01 AIR CONDITIONING SYSTEM 06C0306-000-00 HOSE 06С0407-000-00 HOSE 46С4558-001-00 COMPRESSOR BRACKET AS 6С7246-000-00 VENT 46С7247-000-00 HEATER MOUNTING 46С7831-000-00 EVAPORATOR AS

1

2

3

4

5

6

7

8

9

10

Позиция на иллюстрации	Заводской номер детали		Название детали
1	22С1606		Bracket as
2	00В0014		Болт
3	00В0012		Болт
4	41С0173		Drive shaft
5	00В0022		Болт
6	06В0003		Шайба
7	06В0037		WASHER
8	20А3042		Cover
9	04В0251		Screw
10	55А1226		Sleeve

Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
