Каталог запасных частей к технике: LiuGong CLG-4165. 11Y0092_003_00 HYDRAULIC SYSTEM

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
3
4
4
5
6
6
7
8
9
9
10
10
10
11
12
13
14
15
15
15
15
16
16
17
18
19
19
20
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
40
40
40
41
41
41
41
41
42
43
44
44
45
45
45
45
45
46
47
48
49
50
50
50
50
50
51
52
52
53
54
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
79
80
87
88
89
90
91
91
92
93
Позиция на иллюстрации Заводской номер детали Название детали
1 12C3175 Hydraulic lock
2 09C0639 Jacket
3 09C0202 Clamp
4 SWINGMOTOR Swing motor
4 11C0783 Swing motor
5 44C1599 Swivel joint
6 44C1634 Hydraulic lock
7 09C0188 Clamp
8 10C0696 Blade swing cylinder
9 10C0695 Blade lift cylinder
10 30C0164 Connector
11 06C7531 Hose
12 09C0380 Clamp
13 00B0056 Болт
14 06B0001 WASHER
15 06B0002 Шайба
16 09C0203 Clamp
17 49Y0039 Platform
18 44C1792 Control valve as
19 09C0126 Хомут двойной
20 00B0005 BOLT
21 44C1773 Return valve
22 44C0085 Joint
23 01B0009 BOLT
24 12B0302 Кольцо круглого сечения
25 66C1494 Hose as
26 09D0318 Tube
27 44C0077 Joint
28 07C4937 Hose as
29 00C3237 Pump oil suction lines
30 82A1524 Pad
31 10C1066 Steering cylinder
32 06C7536 Hose as
33 06C7528 Hose as
34 02A0281 Tee
35 05C5637 Hose as
36 66C1495 Hose as
37 HOSEAS Hose as
38 HOSEAS Hose as
39 BOLT BOLT
40 06B0008 Шайба
40 06B0008 Шайба
40 06B0008 Шайба
40 06B0008 Шайба
41 06B0007 WASHER
41 06B0007 WASHER
41 06B0007 WASHER
41 06B0007 WASHER
42 44C1791 Control valve as
43 44C1633 Hydraulic lock
44 06C7533 Hose
45 06C9316 Hose
45 06C9316 Hose
45 06C9316 Hose
45 06C9316 Hose
46 10C0694 Blade sideshift cylinder
47 10C0669 Blade pitch cylinder
48 31C0145 Connector
49 06C7535 Hose
50 03B0053 NUT
50 03B0053 NUT
50 03B0053 NUT
50 03B0053 NUT
51 01B0083 Болт
52 46D1761 Stop plate
53 09C0795 Clamp
54 37B0010 Соединения блокировочного кабеля
55 10C0663 Front wheel tilt cylinder
56 06C6762 Hose as
57 66C0158 Hose as
58 66C0157 Hose as
59 HOSEAS Hose as
60 HOSEAS Hose as
61 06C7534 Hose as
62 66C0436 Hose as
63 37B0004 Хомут
64 66C0156 Hose as
65 66C2287 Hose as
66 66C2285 Hose as
67 10C0668 Blade pitch cylinder
68 06B0064 Шайба
69 06C7529 Hose
70 84A0341 Grommet
71 66C1496 Hose as
72 07C4682 Hose as
73 07C4683 Hose as
74 32C0114 Tee
75 06C7530 Hose as
76 06B0006 Шайба
77 00B0075 BOLT
78 CLAMP CLAMP
79 07C4684 Hose as
80 44C1793 Spacer connector
82 CLAMP CLAMP
83 00B0070 BOLT
84 06B0005 WASHER
85 CLAMP CLAMP
86 CLAMP CLAMP
87 66C2005 Hose as
88 66C2006 Hose as
89 PUMPAS Pump as
90 09C1610 Clamp
91 66C2286 Hose as
92 05C2085 Hose as
93 32C0111 Tee
94 30C0166 Connector
