Каталог запасных частей к технике: LiuGong CLG-375A. 46C1627 008 FRAME WIRING AS
1
1
2
3
4
5
6
7
8
8
9
9
10
10
12
12
13
14
14
15
16
16
17
17
23
24
25
26
27
27
28
28
29
29
30
32
33
34
35
35
36
37
38
39
40
40
41
42
43
44
45
46
47
48
49
50
51
52
52
53
53
54
54
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 37B0427 | BATTERY | |
| 2 | 03B0053 | NUT | |
| 3 | 06B0001 | WASHER | |
| 4 | 06B0347 | WASHER | |
| 5 | 00D1649 | BRACKET | |
| 6 | 08C1540 | CABLE | |
| 7 | 08C4937 | HARNESS | |
| 8 | 37B0004 | Хомут | |
| 9 | 86A0286 | SUPPORT | |
| 10 | 04B0073 | Винт | |
| 12 | 09K0002 | Хомут | |
| 13 | 08K0010 | CABLE | |
| 14 | 37B0220 | WASHER | |
| 15 | 30B0311 | FUEL LEVEL SENSOR | |
| 16 | 06B0361 | WASHER | |
| 17 | 06B0066 | WASHER | |
| 23 | 30B0263 | TEMP CONTROL SWITCH | |
| 24 | 06B0117 | Шайба | |
| 25 | 03B0014 | SCREW | |
| 26 | 46C2762 | PROTECTIVE SHIELD | |
| 27 | 00B0075 | BOLT | |
| 28 | 06B0348 | WASHER | |
| 29 | 06B0005 | WASHER | |
| 30 | 37B0328 | WIPER CONTROLLER | |
| 32 | 84A0423 | Пластина | |
| 33 | 46C1865 | FUSE/RELAY AS | |
| 34 | 46C1847 | RELAY MOUNTING AS | |
| 35 | 00B0153 | BOLT | |
| 36 | 08C1541 | CABLE | |
| 37 | 03B0021 | NUT | |
| 38 | 21A7931 | PLATE | |
| 39 | 21A7932 | PLATE | |
| 40 | 34V0045 | PROXIMITY SWITCH | |
| 41 | 20A4618 | PLATE | |
| 42 | 20A4617 | PLATE | |
| 43 | 37B0276 | LIGHTER | |
| 44 | 01B0529 | SCREW ROD | |
| 45 | 06B0346 | WASHER | |
| 46 | 06B0024 | WASHER | |
| 47 | 74A4060 | FUSE NAMEPLATE | |
| 48 | 74A4061 | FUSE NAMEPLATE | |
| 49 | 10A7409 | MOUNTING PLATE | |
| 50 | 34B0147 | Выключатель аварийной сигнализации | |
| 51 | 10A7425 | MOUNTING PLATE | |
| 52 | 06B0097 | Шайба | |
| 53 | 06B0022 | Шайба | |
| 54 | 04B0198 | Болт |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
