Каталог запасных частей к технике: LiuGong CLG-365A. 23E0499 002 HEATING SYSTEM
1
2
3
4
5
5
6
7
8
9
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
25
25
26
27
28
29
30
31
32
32
33
34
35
36
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 86A0790 | AIR DUCT | |
| 2 | 10A4796 | PLATE | |
| 3 | 00D4333 | JOINT | |
| 4 | 00B0022 | BOLT | |
| 5 | 06B0346 | WASHER | |
| 6 | 85A1775 | HEAT INSULATION PLATE | |
| 7 | 15B0062 | CLAMP | |
| 8 | 86A0792 | AIR DUCT | |
| 9 | 85A1766 | HEAT INSULATION PLATE | |
| 11 | 85A2117 | HEAT SHIELD | |
| 12 | 30A0020 | Hose | |
| 13 | 46C1663 | WATER INTAKE VALVE | |
| 14 | 46C3565 | VENT | |
| 15 | 04B0112 | SCREW | |
| 16 | 46C3600 | VENT | |
| 17 | 86A0789 | AIR DUCT | |
| 18 | 85A2118 | HEAT SHIELD | |
| 19 | 46C7631 | Heater | |
| 20 | 85A1769 | HEAT INSULATION PLATE | |
| 21 | 85A3928 | Heat shield | |
| 22 | 00B0012 | BOLT | |
| 23 | 06B0347 | WASHER | |
| 24 | 06B0001 | WASHER | |
| 25 | 02B0148 | BOLT | |
| 26 | 00D4328 | PLATE | |
| 27 | 46C3593 | STRAINER | |
| 28 | 37B1043 | Protective pipe | |
| 29 | 15B0009 | CLAMP | |
| 30 | 37B0004 | Хомут | |
| 31 | 01A0364 | CONNECTOR | |
| 32 | 20A8522 | PLATE | |
| 33 | 85A3927 | Heat shield | |
| 34 | 03B0036 | NUT | |
| 35 | 06B0024 | WASHER | |
| 36 | 10A9119 | Plate |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
