Позиция на иллюстрации
Заводской номер детали
Название детали
3
992014014
MOTOR BRACKET
4
992014114
MOTOR BRACKET
5
726628314
RUBBER MOUNT
6
726628814
RUBBER MOUNT
60
4900100
HEX BOLT
62
4900123
HEX BOLT
63
4900153
HEX BOLT
64
406855103
DOUBLE-ENDED STUD
70
460022703
WASHER
71
460024203
WASHER
80
411900914
NUT
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
