Каталог запасных частей к технике: Komatsu D85C-21A. MARK (ENGLISH)

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
5
6
7
8
9
10
11
12
13
15
16
17
18
19
20
20
21
22
23
24
25
26
27
28
29
30
31
31
32
33
33
34
35
36
37
38
39
40
Позиция на иллюстрации Заводской номер детали Название детали
1 156-98-11112 CHART,LUBRICATION
2 175-900-2350 PLATE, CAUTION, TRAVELING ON SLOPE
3 09649-03001 PLATE, INSTRUCTION,ENGINE STOP
4 09650-30101 PLATE, INSTRUCTION, RADIATOR WATER LEVEL
5 09651-03000 PLATE, SAFETY, BEFORE OPERATING
6 09652-30101 PLATE, CAUTION,FUEL TANK
7 09653-03000 PLATE, SAFETY, HYDRAULIC OIL TANK
8 176-98-43340 PLATE
9 176-98-43240 PLATE
10 09656-30080 PLATE, INSTRUCTION, FUEL TANK STRAINER
11 09657-03000 PLATE, SAFETY, TRACK ADJUSTING
12 09666-03000 PLATE, SAFETY, FIRE PREVENTION
13 09667-03000 PLATE, SAFETY, ENGINE SIDE COVER
14 09668-03000 PLATE, SAFETY, RADIATOR CAP
15 09609-34008 PLATE, NAME
16 09683-30060 PLATE, OPERATING
17 09690-B0450 PLATE, MARK
18 09685-00001 PLATE, OPERATING, RIPPER LOCK LEVER
19 09685-00002 PLATE, OPERATING, LOCK LEVER
20 156-98-11121 MARK
21 09690-B0500 PLATE, MARK
22 09602-10001 PLATE, NAME
23 04418-13060 SCREW
24 09685-00001 PLATE, OPERATING, RIPPER LOCK LEVER
25 176-98-43150 PLATE
26 09685-00004 PLATE, OPERATING, ENGLISH
27 176-98-43161 PLATE
28 04418-13060 SCREW
29 176-98-43331 PLATE
30 176-98-43191 PLATE
31 176-98-43210 PLATE
32 156-98-11262 PLATE
33 09601-60000 PLATE, NAME
33 09601-00835 PLATE, NAME
34 04418-13060 SCREW
35 09690-B0500 PLATE, MARK
36 176-43-42260 GUIDE
37 196-98-31180 PLATE
38 156-98-21150 PLATE
39 09669-0000E PLATE, CAUTION
40 09963-A1640 TAG
