VANDALISM PROTECTION(35001-)
MARKS AND PLATES (ENGLISH)(35001-)
MARKS AND PLATES (ARABIC)(35001-)
MARKS AND PLATES (INDONESIAN)(35063-)
MARKS AND PLATES (SPANISH)(35001-)
MARKS AND PLATES (CHINESE)(35001-)
MARKS AND PLATES (FRENCH)(35063-)
MARKS AND PLATES (PERSIAN)(35001-)
MARKS AND PLATES (ENGLISH¤TRIMMING)(36441-)
TOOL(35001-)
KIT(35001-)
G-1
1
1
2
3
3
4
4
5
5
6
7
8
9
10
11
12
13
14
14
15
16
17
Позиция на иллюстрации
Заводской номер детали
Название детали
G-1
154-00-X7700
VANDALISM CAP GROUP
1
07093-20000
CAP
1
07053-00002
GASKET
2
07091-21200
CAP, FUEL TANK
3
07092-00000
CAP
3
07051-00003
GASKET
4
07092-00000
CAP
4
07051-00003
GASKET
5
09460-00003
LOCK
6
154-55-18510
COVER
7
198-54-19150
SPRING
8
01010-50612
BOLT
9
01602-20619
WASHER, SPRING
10
154-55-18520
PLATE
11
135-54-15191
COLLAR
12
01010-51230
BOLT
13
01010-51225
BOLT
14
01602-31236
WASHER, SPRING
15
01640-21223
WASHER
16
01643-31232
WASHER
17
09460-00000
LOCK
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
Дополнительная информация
×
Название:
Номер:
Примечание:
/200.gif)
