Позиция на иллюстрации
Заводской номер детали
Название детали
176-76-01008
176-76-01008
WINCH ASS'Y
1
176-76-66310
CASE
2
07042-00211
PLUG
3
175-49-21733
COVER
4
6003200-4-40
SPRING
5
07000-42115
O-RING
6
01010-81440
BOLT
7
01602-21442
WASHER, SPRING
8
07042-20108
PLUG, TAPER
9
144-60-11160
ELEMENT
10
176-76-24120
CAGE
11
170-14-18171
SLEEVE
12
170-14-18161
SPRING
13
145-49-12460
BOLT
14
01590-20607
NUT
15
04050-01215
PIN,COTTER
16
176-76-24130
CAGE
17
01010-81060
BOLT
18
01010-81030
BOLT
19
01602-31030
WASHER,SPRING
20
07000-43038
O-RING
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
