Каталог запасных частей к технике: JCB VMТ-270/280. Гидромотор/Hydro motor
10
12
13
15
15
25
27
27
40
41
42
45
47
48
50
52
59
70
71
72
73
74
75
76
77
78
90
91
100
101
102
106
107
108
109
110
111
112
113
135
135
141
142
143
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 10 | 04053/40655 | Cylinder block, cpl. | |
| 12 | 04053/40656 | Piston | |
| 13 | 04053/40657 | Piston | |
| 15 | 04053/40658 | Sealing kit | |
| 25 | 04053/40659 | Housing, cpl. | |
| 27 | 04053/40660 | O-ring | |
| 40 | 04053/40665 | Cover, cpl. | |
| 41 | 04053/40666 | Cover | |
| 42 | 04053/40667 | Screw | |
| 45 | 04053/40668 | O-ring | |
| 47 | 04053/40669 | Distributor | |
| 48 | 04053/40670 | Sealing kit | |
| 50 | 04031/13186 | Screw plug | |
| 52 | 04902/30026 | Spring | |
| 59 | 04053/40671 | Pin | |
| 70 | 04053/40675 | Bearing, cpl. | |
| 71 | 04053/40672 | Housing | |
| 72 | 04053/40673 | Gasket | |
| 73 | 04053/40674 | Bearing | |
| 74 | 04053/40676 | Bearing | |
| 75 | 04053/40677 | Spacer washer | |
| 76 | 04053/40696 | Back-up ring | |
| 77 | 04053/40678 | Retaining ring | |
| 78 | 04053/40679 | Back-up ring | |
| 90 | 04053/40680 | Shaft | |
| 91 | 04053/40681 | Haedless screw | |
| 100 | 04053/40685 | Brake, cpl. | |
| 101 | 04053/40686 | Housing | |
| 102 | 04053/40687 | Screw | |
| 106 | 04053/40688 | O-ring | |
| 107 | 04053/40689 | Brake piston | |
| 108 | 04053/40697 | Gasket | |
| 109 | 04053/40690 | Retaining ring | |
| 110 | 04053/40691 | Brake shaft | |
| 111 | 04053/40692 | Gasket | |
| 112 | 04029/04422 | Screw | |
| 113 | 04029/04421 | Gasket | |
| 135 | 04053/40693 | Sealing kit | |
| 141 | 04053/40694 | Cap | |
| 142 | 07130/21830 | Plug | |
| 143 | 04053/40695 | Gasket | |
| 04053/40650 | 04053/40650 | Hydro motor | |
| 04053/40651 | 04053/40651 | Sealing kit 27,45,106,111,113,141, |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
