Каталог запасных частей к технике: JCB VM-75D/PD. Гидромотор/Fixed displacement hydro motor
5
6
7
8
12
14
15
16
20
22
25
27
30
33
35
40
41
42
42
43
44
44
45
47
47
48
50
51
51
52
60
61
65
66
67
68
69
70
71
72
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 5 | 07225/20256 | Housing | |
| 6 | 07225/20257 | Plate | |
| 7 | 04010/22968 | Disc | |
| 8 | 07225/20258 | Shaft | |
| 12 | 04010/22970 | Disc | |
| 14 | 07225/20259 | Ring | |
| 15 | 04010/22971 | Roller bearing | |
| 16 | 04010/22972 | Roller bearing | |
| 20 | 07210/10215 | Shaft seal ring | |
| 22 | 07210/10216 | O-ring | |
| 25 | 04010/22973 | Retaining ring | |
| 27 | 04010/22974 | Cap screw | |
| 30 | 04010/22975 | Screw plug | |
| 33 | 07222/30453 | Parallel pin | |
| 35 | 04010/46827 | Parallel pin | |
| 40 | 07225/20260 | Piston | |
| 41 | 07222/20629 | Piston | |
| 42 | 07222/20630 | Screw plug | |
| 43 | 07222/20631 | Screw plug | |
| 44 | 07225/20262 | Washer | |
| 45 | 07225/20263 | Visor | |
| 47 | 07222/20634 | Compression spring | |
| 48 | 07222/20635 | Compression spring | |
| 50 | 07222/20636 | O-ring | |
| 51 | 07222/20637 | O-ring | |
| 52 | 07222/20638 | Retaining ring | |
| 60 | 04010/22990 | Driving gear | |
| 61 | 04010/22995 | Connection plate | |
| 65 | 07225/20270 | Piston, kpl. | |
| 66 | 07225/20271 | Cylinder | |
| 67 | 04010/22982 | Plate | |
| 68 | 04010/22983 | Ball | |
| 69 | 04010/22984 | Compression spring | |
| 70 | 04010/22985 | Pin | |
| 71 | 04010/22986 | Retaining ring | |
| 72 | 04010/22987 | Supporting ring | |
| 04010/22965 | 04010/22965 | Driving gear | |
| 07225/20250 | 07225/20250 | Fixed displacement hydro motor | |
| 07225/20251 | 07225/20251 | Sealing kit |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
