Каталог запасных частей к технике: JCB VM-200D/PD. Гидромотор
1
2
2
3
4
9
10
11
12
14
15
16
17
18
19
20
20
21
22
22
24
25
26
27
28
29
30
31
32
33
35
35
35
35
35
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 07260/10202 | Housing | |
| 2 | 04030/67193 | Screw plug | |
| 3 | 04030/67226 | Screw plug, cpl. | |
| 4 | 07240/60604 | Cylinder block | |
| 9 | 07240/60609 | Piston, cpl. | |
| 10 | 07240/60610 | Bracket | |
| 11 | 07260/10211 | Guide | |
| 12 | 07260/10212 | Ring | |
| 14 | 07260/10214 | Pipe | |
| 15 | 07260/10215 | Valve plate | |
| 16 | 07260/10216 | Thrust plate | |
| 17 | 07260/10217 | Housing | |
| 18 | 04029/16311 | Parallel pin | |
| 19 | 07260/10219 | Gasket | |
| 20 | 04030/67219 | Screw plug | |
| 21 | 07260/10221 | Hexagon screw | |
| 22 | 07260/10222 | Hexagon screw | |
| 23 | 07260/10223 | Hexagon screw | |
| 24 | 07260/10224 | Piston | |
| 25 | 07260/10225 | Spring retainer | |
| 26 | 07240/13339 | Spring | |
| 27 | 07260/10227 | Screw plug, cpl. | |
| 28 | 07261/20205 | Valve | |
| 29 | 07260/10229 | Cylindrical roller bearing | |
| 30 | 07260/10230 | Shaft | |
| 31 | 07260/10231 | Retaining ring | |
| 32 | 07260/10232 | Thrust washer | |
| 33 | 04029/16332 | Cap screw | |
| 35 | 04029/16307 | O-ring | |
| 07260/10201 | 07260/10201 | Kit, gasket | |
| 07261/20200 | 07261/20200 | Fixed displacement hydro motor |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
