Каталог запасных частей к технике: Hyundai R330LC-9SH. TRAVEL MOTOR (1/2)
XKAY-00238
XKAY-00278
2
33
35
37
37
38
38
38
39
39
39
39
40
40
41
41
42
43
44
45
46
47
48
49
49
50
50
51
52
53
54
54
54
55
55
55
56
57
58
59
60
61
62
63
64
65
66
68
70
71
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| XKAY-00238 | XKAY-00238 | SPOOL KIT-C/BLC VALVE | |
| XKAY-00278 | XKAY-00278 | SEAL KIT | |
| 31Q9-40031 | 31Q9-40031 | TRAVEL MOTOR | |
| 31Q9-40010 | 31Q9-40010 | TRAVEL UNIT | |
| ReductionGear | ReductionGear | T/Reduction Gear | |
| 2 | XKAY-01415 | PLUG | |
| 33 | XKAY-01416 | CASING-VALVE | |
| 35 | XKAY-00236 | O-RING | |
| 37 | XKAY-00239 | SPOOL-C/BLC VALVE | |
| 38 | XKAY-00240 | SCREW-ORIFICE | |
| 39 | XKAY-00241 | DAMPING CHECK ASSY | |
| 40 | XKAY-00242 | SPRING-C/BLC VALVE | |
| 41 | XKAY-00243 | O-RING | |
| 42 | XKAY-00244 | PLUNGER-C/BLC VALVE | |
| 43 | XKAY-00245 | SPRING-CHECK | |
| 44 | XKAY-00246 | STOPPER-CHECK | |
| 45 | XKAY-00247 | O-RING | |
| 46 | XKAY-00248 | RING-BACK UP | |
| 47 | XKAY-00249 | CAP-C/BLC VALVE | |
| 48 | XKAY-00250 | CAP-C/BLC VALVE | |
| 49 | XKAY-00136 | BOLT-SOCKET | |
| 50 | XKAY-00251 | BOLT-SOCKET | |
| 51 | XKAY-00252 | SEAT | |
| 52 | XKAY-00253 | BALL-STEEL | |
| 53 | XKAY-00254 | STOPPER | |
| 54 | XKAY-00255 | PLUG-HP | |
| 55 | XKAY-00256 | O-RING | |
| 56 | XKAY-00257 | PLUG-HP | |
| 57 | XKAY-01130 | RELIEF VALVE ASSY | |
| 58 | XKAY-00259 | O-RING | |
| 59 | XKAY-00260 | RING-BACK UP | |
| 60 | XKAY-00261 | ROD-SWASH | |
| 61 | XKAY-00262 | O-RING | |
| 62 | XKAY-00263 | SCREW-LOCK | |
| 63 | XKAY-00279 | NUT-HEX | |
| 64 | XKAY-00265 | SPOOL-SWASH | |
| 65 | XKAY-00266 | PLUG | |
| 66 | XKAY-00267 | O-RING | |
| 68 | XKAY-00269 | SPRING-SWASH | |
| 70 | XKAY-00271 | BOLT-WRENCH | |
| 71 | XKAY-00272 | BOLT-SOCKET |
