1
3
4
4
5
5
7
9
10
11
11
12
12
Позиция на иллюстрации
Заводской номер детали
Название детали
31940-72001
31940-72001
Fuel Filter Assy
1
31944-72000
Head-Fuel Filter
3
31945-72001
Element-Fuel Filter
4
31942-72000
Болт-проушина
5
31941-72000
Gasket
7
31943-72000
Cock-Air Vent
9
11964-10351
Bolt-Sems
10
31949-83C01
Connector
11
31947-83C10
Bracket-Fuel Filter
11
31948-83C10
Bracket-Fuel Filter
12
15705-10201
Nipple-Grease
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
