1
2
3
4
5
6
7
8
9
9
10
Позиция на иллюстрации
Заводской номер детали
Название детали
3936315
3936315
Head-Fuel Filter
3905860
3905860
Screw
1
3903293
Nut
2
11E1-70010
Filter-Fuel
3
3925955
Adapter-Filter Head
4
3905403
Screw
5
3911446
Screw
6
3906694
Seal-Rect Ring
7
3906695
Seal-Rectangular Ring
8
3936313
Head-Fuel Filter
9
3935171
Washer-Sealing
10
11E1-70210
Filter-Fuel&W/Separator
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
