81N8-14103
81N8-14112
81N8-14290
81N8-15015GG
1
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Позиция на иллюстрации
Заводской номер детали
Название детали
81N8-14015GG
81N8-14015GG
T/CYLINDER ASSY
IDLER
IDLER
IDLER ASSY
81N8-14103
81N8-14103
BODY
81N8-14112
81N8-14112
BAR-TIE
81N8-14290
81N8-14290
PIN-SPRING
81N8-15015GG
81N8-15015GG
ADJUST COMPONENT
1
81N8-14303
BODY ASSY
3
81N8-14121
SPRING
4
81N8-14132
BRACKET
5
81E9-20153
NUT LOCK
6
81E9-20161
PLATE-LOCK
7
S018-120306
BOLT-HEX
8
S411-120006
WASHER-SPRING
9
81E1-3104
PACKING-ROD
10
81E1-3204
RING-BACK UP
11
81E1-3304
SEAL-DUST
12
81N8-14211
ROD
13
81N6-14240
VALVE-GREASE
14
81N8-14271
TUBE
15
S018-16050D
BOLT-HEX
16
S411-160006
WASHER-SPRING
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
