Каталог запасных частей к технике: Hyundai R210W-9. CAB ASSY (4/4, DOOR)

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
1-3
10
11
12
13
13
14
16
17
17
19
19
2-1
2-10
2-11
2-12
2-13
2-14
2-14
2-2
2-3
2-4
2-5
2-6
2-7
2-7
2-8
2-9
20
21
22
23
24-1
24-2
24-3
26
27
28
29
3
30
4
5-1
5-10
5-11
5-15
5-16
5-2
5-3
5-4
5-5
5-6
5-7
5-8
5-9
6
7
9
2-15
Позиция на иллюстрации Заводской номер детали Название детали
CAB CAB CAB ASSY
71Q6-02001 71Q6-02001 Side Door Assy
71Q6-02002 71Q6-02002 SIDE DOOR ASSY
71Q6-02002 71Q6-02002 SIDE DOOR ASSY
1 71Q6-02012 SIDE DOOR WA
1 71Q6-02013 Side Door Wa
1-3 71Q6-02102 HINGE
10 S778-021900 WEATHER STRIP
10 71Q6-02380 Weather Strip
10 S778-021900 WEATHER STRIP
11 71M8-00680 RUBBER-CAP
12 71N6-03650 STRIKER
13 17E1-5146 BUMPER-DOOR
14 S205-10100B NUT-HEX
16 S131-043046 SCREW-W/WASHER
17 S151-050156 SCREW-TAPPING
19 S411-050006 WASHER-SPRING
2 71Q6-02020 SASH ASSY
2-1 71Q6-03231 GLASS-FRONT
2-1 71Q6-03230 Glass
2-1 71Q6-03231 GLASS-FRONT
2-10 71Q6-03320 LOCK
2-11 71Q6-03330 LOCK
2-12 71Q6-03340 LOCK
2-13 71Q6-03350 CATCH
2-14 71Q6-03360 RUBBER
2-2 71Q6-03241 GLASS-REAR
2-2 71Q6-03240 Glass
2-2 71Q6-03241 GLASS-REAR
2-3 71Q6-03251 FRAME
2-3 71Q6-03250 Frame
2-3 71Q6-03251 FRAME
2-4 71Q6-03260 MOHAIR
2-5 71Q6-03271 RAIL
2-5 71Q6-03270 Rail
2-5 71Q6-03271 RAIL
2-6 71Q6-03280 Rail
2-6 71Q6-03281 RAIL
2-7 71Q6-03291 RAIL
2-7 71Q6-03290 Rail
2-7 71Q6-03291 RAIL
2-8 71Q6-03300 SEAL
2-9 71Q6-03310 LOCK ASSY
20 S776-050300 WEATHER STRIP
20 71Q6-02040 Weather Strip
20 S776-050300 WEATHER STRIP
21 S161-060156 SCREW-CROSS R/ROUND
22 S411-060006 WASHER-SPRING
23 S403-062006 Washer-Plain
24 71Q6-02080 Stopper Assy
24 71Q6-02081 Stopper Assy
24 71Q6-02082 STOPPER ASSY
24-1 71Q6-02260 Bolt-Knob
24-1 71Q6-02261 Bolt-Knob
24-1 71Q6-02262 BOLT-KNOB
24-2 71Q6-02290 RUBBER-BUMPER
24-3 71Q6-02280 Plate
24-3 71Q6-02280 Plate
24-3 71Q6-02281 PLATE
26 S037-082526 BOLT-W/WASHER
27 S141-060166 SCREW-FLAT HD
28 71Q6-02110 Latch Assy
28 72Q6-02110 HANDLE-OUTER
29 71Q6-00590 Plate-Assit
3 71Q6-02031 GLASS-DOOR
3 71Q6-02030 Glass-Door
3 71Q6-02031 GLASS-DOOR
30 71Q6-02050 ROTOR
4 71Q6-02242 HANDRAIL
5 71Q6-02121 Handle Assy
5 72Q6-02120 Handle Assy
5 72Q6-02121 HANDLE ASSY
5-1 71Q6-02131 Latch-Door
5-1 71Q6-02130 Catch
5-1 71Q6-02131 Latch-Door
5-10 MB700270 Washer-Plate
5-11 MH650620 Pin-R
5-15 72Q6-02130 Latch Assy-Inner
5-15 72Q6-02131 LATCH ASSY-INNER
5-16 72Q6-02140 LEVER ASSY
5-2 71Q6-03150 Knob-Inner Handle
5-3 71Q6-02150 Handle-Inner
5-4 71Q6-02170 Rod
5-5 71Q6-02180 Rod
5-6 71Q6-02160 Rod
5-7 71Q6-02190 Rod
5-8 71Q6-02250 Holder
5-9 MH800050 Pin-Joint
6 71Q6-02140 COVER
7 71Q6-02061 COVER
9 S778-021500 WEATHER STRIP
9 71Q6-02370 Weather Strip
9 S778-021500 WEATHER STRIP
2-15 71Q6-03370 FRAME-LOWER
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
