Каталог запасных частей к технике: Hyundai R210NLC-9. MAIN PUMP (2/2)
XJBN-01039
111
113
122
123
124
124
126
126
127
128
128
129
129
171
191
192
261
271
406
408
469
490
492
709
724
726
728
735
751
774
823
823
824
825
825
826
826
827
828
828
887
888
901
901
S541
S541
S543
S543
S545
S545
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| XJBN-01039 | XJBN-01039 | Piston Sub Assy | |
| MainPump | MainPump | Main Pump | |
| 111 | XJBN-00790 | Shaft-Drive | |
| 113 | XJBN-00789 | Shaft-Driven | |
| 122 | XJBN-00788 | Bearing-Roller | |
| 123 | XJBN-00787 | Bearing-Roller | |
| 124 | XJBN-00786 | Bearing-Needle | |
| 126 | XJBN-00785 | Spacer-Bearing | |
| 127 | XJBN-00081 | Spacer-Bearing | |
| 128 | XJBN-00784 | Spacer-Bearing | |
| 129 | XJBN-00569 | SPACER-BEARING | |
| 171 | XJBN-00783 | Casing-Front | |
| 191 | XJBN-00782 | Gear-Drive | |
| 192 | XJBN-00781 | Gear-Driven | |
| 261 | XJBN-00778 | Cover-Front | |
| 271 | XJBN-00777 | Casing-Pump | |
| 406 | XJBN-00355 | Screw | |
| 408 | XJBN-00695 | Screw-Hex | |
| 469 | XJBN-00238 | Plug | |
| 490 | XJBN-00032 | PLUG | |
| 492 | XJBN-00772 | Restrictor | |
| 709 | XJBN-00387 | O-Ring | |
| 724 | XJBN-00044 | O-RING | |
| 726 | XJBN-00231 | O-RING | |
| 728 | XJBN-00046 | O-RING | |
| 735 | XJBN-00280 | O-RING | |
| 751 | XJBN-00764 | Packing | |
| 774 | XJBN-00762 | Seal-Oil | |
| 823 | XJBN-00759 | Ring-Snap | |
| 824 | XJBN-00102 | Ring-Snap | |
| 825 | XJBN-00508 | Ring-Snap | |
| 826 | XJBN-00052 | RING-SNAP | |
| 827 | XJBN-00489 | Ring-Snap | |
| 828 | XJBN-00130 | Ring-Snap | |
| 887 | XJBN-00758 | Pin-Spring | |
| 888 | XJBN-00712 | Pin | |
| 901 | XJBN-00104 | Bolt-Eye | |
| S | XJBN-01127 | Check Valve Assy | |
| S541 | XJBN-00767 | Seat | |
| S543 | XJBN-00766 | Stopper 1 | |
| S545 | XJBN-00765 | Ball-Steel |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
