Каталог запасных частей к технике: Hyundai R210NLC-9. COOLING SYSTEM
2
3
4
5
6
7
7
8
9
9
10
10
11
12
13
13
14
14
15
16
17
18
18
19
19
19
19
19
19
19
20
21
21
22
22
23
24
25
25
25
25
26
26
27
27
28
28
29
29
30
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 11Q6-40830 | 11Q6-40830 | Bracket | |
| 11Q6-44011 | 11Q6-44011 | Hose-Upper | |
| 11U2-40190 | 11U2-40190 | Clamp-T-Retention | |
| 11Q6-40820 | 11Q6-40820 | Pipe-Cac | |
| 2 | S017-16045D | BOLT-HEX | |
| 3 | S441-160006 | WASHER-HARDENED | |
| 4 | 11Q8-40240 | Hose-Lower | |
| 5 | 11Q6-44010 | Hose-Upper | |
| 6 | S572-590006 | Clamp-Hose,Wire Type | |
| 7 | S572-630006 | Clamp-Hose,Wire Type | |
| 8 | S572-650006 | Clamp-Hose,Wire Type | |
| 9 | 11N6-46150 | STAY | |
| 10 | S037-123026 | BOLT-W/WASHER | |
| 11 | 11Q6-40551 | Bracket | |
| 12 | 11Q6-40560 | Bracket | |
| 13 | S037-102526 | BOLT-W/WASHER | |
| 14 | 11Q6-40470 | Hose-Cac | |
| 15 | 11Q6-40490 | Pipe | |
| 16 | 11Q6-40570 | Hose-Cac | |
| 17 | 11Q6-40480 | Pipe | |
| 18 | 11Q6-40530 | Hose-Cac | |
| 19 | 11Q4-44310 | Clamp | |
| 20 | 11Q4-44320 | Clamp | |
| 21 | 11Q6-40690 | U-Bolt | |
| 22 | S275-12000B | Nut-Self Locking | |
| 23 | E111-2504 | HOSE | |
| 24 | 12L1-3011 | HOSE-AIR VENT | |
| 25 | S520-015000 | CLAMP-HOSE,S/DRIVE | |
| 26 | 11Q6-44041 | Screen | |
| 27 | 31L7-10190 | CLAMP-TUBE | |
| 28 | 31L7-10200 | CLAMP-TUBE | |
| 29 | S035-081556 | BOLT-W/WASHER | |
| 30 | 11N6-43280 | U-Bolt |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
