Каталог запасных частей к технике: Hyundai R210LC-9. REGULATOR
412
413
436
438
438
438
496
708
722
724
725
728
730
732
733
734
735
753
755
755
756
763
801
802
814
858
858
924
N601
N611
N612
N613
N614
N615
N621
N622
N623
N624
N625
N626
N627
N628
N629
N630
N631
N641
N643
N644
N645
N646
N651
N652
N653
N654
N655
N656
N836
N874
N875
N875
N876
N876
N887
N897
N898
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| XJBN-01641 | XJBN-01641 | Regulator | |
| XJBN-00314 | XJBN-00314 | LEVER-2 | |
| XJBN-00793 | XJBN-00793 | Stem(Q)-Adjust | |
| XJBN-00295 | XJBN-00295 | SPRING-PILOT | |
| XJBN-01553 | XJBN-01553 | Regulator Ass'Y | |
| 412 | XJBN-00321 | SCREW-HEX | |
| 413 | XJBN-00320 | SCREW-HEX | |
| 436 | XJBN-00319 | SCREW-HEX | |
| 438 | XJBN-00318 | SCREW-HEX | |
| 496 | XJBN-00032 | PLUG | |
| 708 | XJBN-00286 | O-RING | |
| 722 | XJBN-00285 | O-RING | |
| 724 | XJBN-00044 | O-RING | |
| 725 | XJBN-00231 | O-RING | |
| 728 | XJBN-00097 | O-RING | |
| 730 | XJBN-00230 | O-RING | |
| 732 | XJBN-00820 | O-RING | |
| 733 | XJBN-00282 | O-RING | |
| 734 | XJBN-00281 | O-RING | |
| 735 | XJBN-00280 | O-RING | |
| 753 | XJBN-01026 | O-RING | |
| 755 | XJBN-00045 | O-RING | |
| 756 | XJBN-00279 | O-RING | |
| 763 | XJBN-00094 | O-RING | |
| 801 | XJBN-00278 | NUT | |
| 802 | XJBN-01027 | NUT | |
| 814 | XJBN-00277 | RING-SNAP | |
| 858 | XJBN-00275 | RING-SNAP | |
| 924 | XJBN-00269 | SCREW-SET | |
| N601 | XJBN-00317 | CASING | |
| N611 | XJBN-00347 | Lever-Feedback | |
| N612 | XJBN-00315 | LEVER-1 | |
| N613 | XJBN-01211 | Lever-2 | |
| N614 | XJBN-00313 | PLUG-CENTER | |
| N615 | XJBN-00312 | PLUG-ADJUST | |
| N621 | XJBN-00311 | PISTON-COMPENSATOR | |
| N622 | XJBN-00346 | CASE-PISTON | |
| N623 | XJBN-01202 | ROD-COMPENSATOR | |
| N624 | XJBN-01203 | SEAT-SPRING | |
| N625 | XJBN-00345 | Spring-Outer | |
| N626 | XJBN-00306 | SPRING-INNER | |
| N627 | XJBN-01031 | STEM(C)-ADJUST | |
| N628 | XJBN-01025 | SCREW(C)-ADJUST | |
| N629 | XJBN-00303 | COVER(C) | |
| N630 | XJBN-00302 | LOCK NUT | |
| N631 | XJBN-00301 | Sleeve | |
| N641 | XJBN-00871 | COVER-PILOT | |
| N643 | XJBN-01205 | PISTON-PILOT | |
| N644 | XJBN-01206 | SEAT-SPRING | |
| N645 | XJBN-01042 | Stem(Q)-Adjust | |
| N646 | XJBN-01379 | Spring-Pilot | |
| N651 | XJBN-00292 | SLEEVE | |
| N652 | XJBN-00291 | SPOOL | |
| N653 | XJBN-00290 | SEAT-SPRING | |
| N654 | XJBN-00289 | SPRING-RETURN | |
| N655 | XJBN-00288 | SPRING-SET | |
| N656 | XJBN-00287 | COVER-BLOCK | |
| N836 | XJBN-00276 | RING-SNAP | |
| N874 | XJBN-00344 | PIN | |
| N875 | XJBN-00273 | PIN | |
| N876 | XJBN-00794 | PIN | |
| N887 | XJBN-00272 | PIN | |
| N897 | XJBN-00795 | PIN | |
| N898 | XJBN-00270 | Pin |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
