Каталог запасных частей к технике: Hyundai R180W-9S. TRAVEL MOTOR (2/2)

Тип техники

Марка

Модель

Схема

1

1-1

1-15

1-16

1-17

1-19

1-2

1-20

1-22

1-23

1-29

1-3

1-4

1-5

1-7

1-9

15

16

2

2-1

2-10

2-12

2-2

23

26

28

29

3

32

33

34

34

4

5

50

50

7

8

XJDD-00683

1-14

1-21

2-11

20

20

Позиция на иллюстрации	Заводской номер детали		Название детали
XJDD-01227	XJDD-01227		CONTROL
1	XJDD-01231		CONTROL PART
1-1	XJDD-01236		HOUSING-CONTROL
1-15	XJDD-00864		SCREW-SOCKET HEAD
1-16	XJDD-00952		SCREW-LOCKING
1-17	XJDD-00953		RING-RETAINING
1-19	XJDD-00954		PIN-THREADED
1-2	XJDD-01237		BUSHING-CONTROL
1-20	XJDD-00955		PIN-CYLINDER
1-22	XJDD-00036		PIN-D/BREAK OFF
1-23	XJDD-00054		PIN-D/BREAK OFF
1-29	XJDD-00957		DISC-RETAINING
1-3	XJDD-01238		PISTON-CONTROL
1-4	XJDD-00947		BUSHING-ADJUSTING
1-5	XJDD-00948		COLLAR-SPRING
1-7	XJDD-00949		SPRING-PRESSURE
1-9	XJDD-00950		SPRING-PRESSURE
15	XJDD-00938		SCREW-SOCKET HEAD
16	XJDD-00939		SCREW-SOCKET HEAD
2	XJDD-01232		COVER
2-1	XJDD-01239		COVER
2-10	XJDD-01241		SOCKET-HEAD SCREW
2-12	XJDD-00952		SCREW-LOCKING
2-2	XJDD-01240		SCREW-THROTTLE
23	XJDD-00940		SCREW-SOCKET HEAD
26	XJDD-00941		PIN-CYLINDER
28	XJDD-00017		PLUG
29	XJDD-01234		PLUG
3	XJDD-01233		PORT PLATE
32	XJDD-00054		PIN-D/BREAK OFF
33	XJDD-00967		SCREW-LOCKING
34	XJDD-00942		SCREW-LOCKING
4	XJDD-00932		PISTON-POSITIONING
5	XJDD-00933		TRUNNION
50	XJDD-00943		RELIEF VALVE
7	XJDD-00934		Piston With Piston Rings
8	XJDD-00935		PIN-THREADED
XJDD-00683	XJDD-00683		Seal Kit
1-14	XJDD-00951		O-RING
1-21	XJDD-00956		NUT-SEAL LOCK
2-11	XJDD-00965		O-RING
20	XJDD-00875		O-RING

Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
