81N5-30040GG
81Q5-30050
1
1
1-1
1-1
2
3
3
4
4
5
6
7
Позиция на иллюстрации
Заводской номер детали
Название детали
81N5-30040GG
81N5-30040GG
PROPELLER SHAFT-FR
81Q5-30050
81Q5-30050
PROPELLER SHAFT-RR
1
XKCP-00030
U/Joint Assy
1-1
XKCP-00023
Nipple-Grease
2
XKCP-00031
Outer-Sliding
3
XKCP-00041
SLIP SHAFT ASSY-FR
3
XKCP-00042
SLIP SHAFT ASSY-RR
4
XKCP-00035
Yoke-Flange
5
XKCP-00002
Nipple-Grease
6
XKCP-00037
Plug-Exp
7
XKCP-00038
Seal-Joint
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
