Каталог запасных частей к технике: Hyundai R180LC-9S. MAIN PUMP
011
013
014
030
111
113
116
123
124
124
127
153
156
157
211
251
261
271
271
312
326
401
401
406
406
414
467
467
468
468
490
530
532
534
535
702
710
711
717
719
724
725
727
728
728
732
774
789
792
808
808
824
885
886
886
886
901
953
954
981
983
NS141
NS151
NS152
NS313
NS314
NS548
S212
S214
S531
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 31Q5-10010 | 31Q5-10010 | Main Pump | |
| MainPumpUnit | MainPumpUnit | Main Pump Unit | |
| 011 | XJBN-01572 | Piston Sub Assy | |
| 013 | XJBN-01048 | Cylinder Sub Assy-Rh | |
| 014 | XJBN-01047 | Cylinder Sub Assy-Lh | |
| 030 | XJBN-00800 | Swash Plate Sub Assy | |
| 111 | XJBN-00802 | Shaft(F)-Drive | |
| 113 | XJBN-00803 | Shaft(R)-Drive | |
| 116 | XJBN-00804 | Gear-1st | |
| 123 | XJBN-00429 | Bearing-Roller | |
| 124 | XJBN-00805 | Bearing-Needle | |
| 127 | XJBN-00806 | Spacer-Bearing | |
| 153 | XJBN-00808 | Plate-Set | |
| 156 | XJBN-00422 | Bushing-Spherical | |
| 157 | XJBN-00421 | Spring-Cylinder | |
| 211 | XJBN-00420 | Plate-Shoe | |
| 251 | XJBN-00417 | Support | |
| 261 | XJBN-00809 | Cover-Fr | |
| 271 | XJBN-01046 | Casing-Pump | |
| 312 | XJBN-00812 | Block-Valve | |
| 326 | XJBN-00937 | Cover | |
| 401 | XJBN-00411 | Screw | |
| 406 | XJBN-00813 | Screw | |
| 414 | XJBN-00160 | Screw-Socket | |
| 466 | XJBN-00030 | PLUG | |
| 467 | XJBN-00487 | Plug | |
| 468 | XJBN-00814 | PLUG | |
| 490 | XJBN-00032 | PLUG | |
| 530 | XJBN-00801 | Tilting Pin Sub Assy | |
| 532 | XJBN-00407 | Piston-Servo | |
| 534 | XJBN-00816 | Stopper | |
| 535 | XJBN-00405 | Stopper | |
| 702 | XJBN-00817 | O-Ring | |
| 710 | XJBN-00387 | O-Ring | |
| 711 | XJBN-00095 | O-Ring | |
| 717 | XJBN-00818 | O-Ring | |
| 719 | XJBN-00819 | O-Ring | |
| 724 | XJBN-00044 | O-RING | |
| 725 | XJBN-00045 | O-RING | |
| 727 | XJBN-00233 | O-RING | |
| 728 | XJBN-00097 | O-RING | |
| 732 | XJBN-00820 | O-RING | |
| 735 | XJBN-00280 | O-RING | |
| 774 | XJBN-01029 | Seal-Oil | |
| 789 | XJBN-00476 | Ring-Back Up | |
| 792 | XJBN-00454 | Ring Back-Up | |
| 808 | XJBN-00101 | Nut-Hex | |
| 824 | XJBN-00821 | Ring-Snap | |
| 885 | XJBN-00394 | Pin-Valve Plate | |
| 886 | XJBN-00054 | PIN-SPRING | |
| 901 | XJBN-00104 | Bolt-Eye | |
| 953 | XJBN-00105 | Screw-Set | |
| 954 | XJBN-00392 | Screw-Set | |
| 981 | XJBN-00156 | NAME PLATE | |
| 983 | XJBN-00455 | Pin | |
| NS141 | XJBN-00807 | Block-Cylinder | |
| NS151 | XJBN-00425 | Piston | |
| NS152 | XJBN-01278 | Shoe | |
| NS313 | XJBN-01045 | Plate(R)-Valve | |
| NS314 | XJBN-01044 | Plate(L)-Valve | |
| NS548 | XJBN-00360 | PIN-FEED BACK | |
| S212 | XJBN-00419 | Plate-Swash | |
| S214 | XJBN-00418 | Bushing-Tilting | |
| S531 | XJBN-00815 | Pin-Tilting |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
