Каталог запасных частей к технике: Hyundai R180LC-9S. MAIN CONTROL VALVE (4/4)
17
17
18
19
21
23
28
28
29
29
29
30
31
32
32
32
34
34
36
36
37
37
43
43
44
48
49
60
61
62
63
63
63
64
64
64
64
65
65
67
67
67
68
68
72
72
73
73
77
77
78
78
78
78
79
79
80
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| ControlValve | ControlValve | Main Control Valve | |
| 17 | XKBF-01307 | Relief Valve-Overload | |
| 18 | XKBF-01418 | Relief Valve-Overload | |
| 19 | XKBF-01309 | Relief Valve-Overload | |
| 21 | XKBF-01525 | Logic Valve-Swing | |
| 23 | XKBF-01313 | On/Off Valve-Option | |
| 28 | XKBF-01252 | Plug | |
| 29 | XKBF-00892 | Plug | |
| 30 | XKBF-01130 | Plug | |
| 31 | XKBF-00933 | Plug | |
| 32 | XKBF-00932 | Plug | |
| 34 | XKBF-01317 | Plug | |
| 36 | XKBF-00487 | Plug | |
| 37 | XKBF-01277 | Plug | |
| 43 | XKBF-00889 | Poppet 1 | |
| 44 | XKBF-00893 | Poppet 2 | |
| 48 | XKBF-00399 | Orifice-Signal | |
| 49 | XKBF-00922 | Filter-Coin Type | |
| 60 | XKBF-01329 | O-Ring | |
| 61 | XKBF-01330 | O-Ring | |
| 62 | XKBF-01331 | O-Ring | |
| 63 | XKBF-01332 | O-Ring | |
| 64 | XKBF-01333 | O-Ring | |
| 65 | XKBF-01259 | O-Ring | |
| 67 | XKBF-01335 | O-Ring | |
| 68 | XKBF-01336 | O-Ring | |
| 72 | XKBF-01282 | O-Ring | |
| 73 | XKBF-01283 | O-Ring | |
| 77 | XKBF-00962 | Ring-Back Up | |
| 78 | XKBF-01193 | Ring-Back Up | |
| 79 | XKBF-00890 | Spring | |
| 80 | XKBF-00894 | Spring |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
