FUEL INJECTION PUMP GENERAL
FEED PUMP
NOZZLE
AUTOMATIC TIMER
FUEL FILTER
STARTER
ALTERNATOR GENERAL
ALTERNATOR
CONTROL SYSTEM
ACCESSORY
OVERHAUL GASKET KIT
102
103
104
105
106
107
108
109
109
109
1
101
110
111
111
112
113
114
114
115
115
116
Позиция на иллюстрации
Заводской номер детали
Название детали
102
GOVERNOR ASSY
GOVERNOR ASSY
103
COVER-CONTROL RACK
COVER-CONTROL RACK
104
NUT
NUT
105
KEY-WOODRUFF
KEY-WOODRUFF
106
WASHER-SPRING
WASHER-SPRING
107
PUMP ASSY-FEED
PUMP ASSY-FEED
108
BOLT-W/WASHER
BOLT-W/WASHER
109
BOLT-W/WASHER
BOLT-W/WASHER
1
32B65-04220
INJECTION PUMP ASSY
101
InjectionBody
Injection Body Assy
110
32B65-09510
OVER-HAUL KIT
111
09103-10260
NUT-CAP
112
09103-10270
NUT-CAP
113
09103-10280
NUT-CAP
114
94914-02141
O-RING
115
94907-21500
RING-SNAP
116
94901-81020
WASHER-COPPER
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
