Каталог запасных частей к технике: Hyundai R180LC-9S. DOUBLE ACTING MAIN PIPING 1 (ADJUST BOOM)
2
4
4
5
6
7
11
12
13
14
15
23
24
26
27
28
29
29
30
30
30
31
33
37
38
38
38
38
40
40
40
40
40
40
41
41
41
41
41
41
41
41
43
43
43
43
44
44
46
71
72
72
72-1
72-2
72-3
72-4
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 31Q5-90220 | 31Q5-90220 | D/Act Main Piping Kit | |
| 2 | 31Q6-90460 | 5-SHUTTLE ASSY | |
| 4 | P913-166035 | Hose Assy-Orfs 0x0 | |
| 5 | P933-126016 | Hose Assy-Orfs 0x90 | |
| 6 | 31N4-96020 | Hose Assy-Orfs 0x90 | |
| 7 | P910-042020 | Hose Assy-Orfs 0x0 | |
| 11 | P910-042048 | Hose Assy-Orfs 0x0 | |
| 12 | P910-042058 | Hose Assy-Orfs 0x0 | |
| 13 | P910-042062 | Hose Assy-Orfs 0x0 | |
| 14 | P910-042082 | Hose Assy-Orfs 0x0 | |
| 15 | P920-042022 | Hose Assy-Orfs 0x45 | |
| 23 | X500-110001 | CONNECTOR-ORFS | |
| 24 | 31N6-25060 | FILTER-LAST GUARD | |
| 26 | X500-110004 | CONNECTOR-ORFS | |
| 27 | X511-112543 | Connector-Long, Orfs | |
| 28 | X511-112548 | Connector-Long, Orfs | |
| 29 | X500-110016 | Connector-Orfs | |
| 30 | X520-110001 | ELBOW-90,ORFS | |
| 31 | 31N6-25110 | ELBOW-90,LONG | |
| 33 | X520-110004 | ELBOW-90,ORFS | |
| 37 | X840-515151 | Tee-R/Type, Swivel, Orfs | |
| 38 | S631-011004 | O-RING | |
| 40 | S631-024004 | O-RING | |
| 41 | S621-011001 | O-RING | |
| 43 | S621-018001 | O-RING | |
| 44 | S621-021001 | O-RING | |
| 46 | S037-102026 | BOLT-W/WASHER | |
| 71 | 31Q4-40830 | SENSOR-PRESSURE | |
| 72 | 31Q6-20050 | VALVE-SOLENOID | |
| 72-1 | 34Q6-20050 | MANIFOLD | |
| 72-2 | XKAL-00016 | Solenoid Valve | |
| 72-3 | XKAL-00050 | Coil-2 | |
| 72-4 | 230.00.064.0 | SEAL |
