Каталог запасных частей к технике: Hyundai R180LC-9S. ADJUST CYLINDER
1
2
3
4
5
10
13
19
20
21
22
23
24
25
27
27
28
29
29
30
30
30
30
K
K6
K7
K8
K9
K11
K12
K14
K15
K16
K17
K17
K18
K18
K26
K26
K26
K26
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 31Q5-53100 | 31Q5-53100 | Adjust Cylinder Assy | |
| 31Y1-23980 | 31Y1-23980 | Adjust Cyl Sub Assy | |
| 1 | 31Y1-23990 | Tube Assy | |
| 2 | 31Y1-24040 | Rod Assy | |
| 3 | 31Y1-24070 | Gland | |
| 4 | S732-095040 | Bushing-Dd2 | |
| 5 | Y191-102000 | Ring-Snap | |
| 10 | Y190-109000 | Ring-Snap | |
| 13 | 31Y1-24080 | Piston | |
| 19 | 31YC-61143 | Nut-Lock | |
| 20 | 31YC-66081 | Washer-Lock | |
| 21 | S109-220704 | Bolt-Socket | |
| 22 | 31Y1-38500 | Pipe Assy-V | |
| 23 | 31Q4-90590 | Safety Lock Valve | |
| 24 | 31Y1-21230 | Elbow-90 | |
| 25 | P174-120102 | Flange-Hyd, Split | |
| 27 | S107-100456 | Bolt-Socket | |
| 28 | S107-101006 | Bolt-Socket | |
| 29 | 31YC-11641 | Bushing-Pin | |
| 30 | S700-095208 | Dust Seal-Dkiy Type | |
| K | 31Y1-24090 | Seal Kit | |
| K6 | Y220-095011 | Seal-Rod | |
| K7 | Y180-095020 | Ring-Back Up | |
| K8 | Y240-095011 | Ring-Buffer | |
| K9 | Y110-095011 | Wiper-Dust | |
| K11 | S631-150004 | O-RING | |
| K12 | S641-150003 | Ring-Back Up | |
| K14 | S632-095004 | O-Ring | |
| K15 | S642-095003 | Ring-Back Up | |
| K16 | Y420-160000 | SEAL-PISTON | |
| K17 | Y310-160200 | Ring-Wear | |
| K18 | Y440-160002 | Ring-Dust | |
| K26 | Y171-019004 | O-RING |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
