81N5-25030GG
81N5-25020GG
81N6-22060GG
81N6-22040GG
81N6-22030GG
81N6-22020GG
81N5-25060GG
81N5-25040GG
1
2
3
4
4
4
4
4
4
4
4
11
12
13
14
15
16
17
17
18
18
Позиция на иллюстрации
Заводской номер детали
Название детали
81N5-25030GG
81N5-25030GG
Track Chain Assy
81N5-25020GG
81N5-25020GG
Track Chain Assy
E181-T0000
E181-T0000
Track Bolt & Nut Kit
81N6-22060GG
81N6-22060GG
Track Chain Assy
81N6-22040GG
81N6-22040GG
Track Chain Assy
81N6-22030GG
81N6-22030GG
Track Chain Assy
81N6-22020GG
81N6-22020GG
Track Chain Assy
81N5-25060GG
81N5-25060GG
Track Chain Assy
81N5-25040GG
81N5-25040GG
Track Chain Assy
1
81N5-27600
Track Link Assy
2
E181-2504
Bolt-Track
3
E181-2505
Nut-Track
4
81N6-24560
Shoe-Track
4
81N6-24540
Shoe-Track
4
81N6-24530
Shoe-Track
4
81N6-24520
Shoe-Track
4
81N5-24560
Shoe-Track
4
81N5-24540
Shoe-Track
4
81N5-24530
Shoe-Track
4
81N5-24520
Shoe-Track
11
E181-2532
Track Link-Rh
12
E181-2531
Track Link-Lh
13
E181-2533
Pin-Track
14
81N5-26140
Bushing-Track
15
E181-2535
Pin-Master
16
E181-2536
Bushing-Master
17
81N4-26210
Seal-Urethane
18
E181-2537
Spacer-Master
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
