Каталог запасных частей к технике: Hyundai R180LC-9. SINGLE ACTING MAIN PIPING KIT
31Q5-90110
1
1
2
3
4
5
5
6
7
7
8
8
9
9
10
11
12
12
13
14
14
15
16
17
18
18
19
19
19
19
20
21
22
23
24
25
25
25
25
25
25
25
26
26
26
27
28
28
28
28
29
29
29
29
29
29
29
29
29
29
29
29
29
29
30
31
31
31
32
32
33
34
34
35
36
37
38
38
39
39
40
40
41
41
210
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 31Q5-90110 | 31Q5-90110 | S/Act Main Piping Kit | |
| 1 | 31N5-94710 | Block-Hose Joint | |
| 2 | 31Q6-91220 | VALVE-SOLENOID | |
| 3 | 31Q4-93370 | Bracket | |
| 4 | 31N6-30130 | TEE-SHUTTLE,S/NUT | |
| 5 | P974-166324 | Hose Assy-Orfs 0x45 | |
| 6 | P933-126019 | Hose Assy-Orfs 0x90 | |
| 7 | P923-123029 | Hose Assy-Orfs 0x45 | |
| 8 | P910-042030 | Hose Assy-Orfs 0x0 | |
| 9 | P910-042037 | Hose Assy-Orfs 0x0 | |
| 10 | P910-042052 | Hose Assy-Orfs 0x0 | |
| 11 | P930-042006 | Hose Assy-Orfs 0x90 | |
| 12 | P930-042010 | Hose Assy-Orfs 0x90 | |
| 13 | P930-042042 | Hose Assy-Orfs 0x90 | |
| 14 | X500-110001 | CONNECTOR-ORFS | |
| 15 | 31N6-25060 | FILTER-LAST GUARD | |
| 16 | X500-110004 | CONNECTOR-ORFS | |
| 17 | 31N4-95290 | Connector | |
| 18 | X511-116556 | Connector-Long, Orfs | |
| 19 | X520-110001 | ELBOW-90,ORFS | |
| 20 | X520-110012 | ELBOW-90,ORFS | |
| 21 | X520-110018 | Elbow-90, Orfs | |
| 22 | X820-045151 | TEE-R/TYPE,ORFS | |
| 23 | X820-065151 | Tee-R/Type, Orfs | |
| 24 | X820-065251 | TEE-R/TYPE,ORFS | |
| 25 | S631-011004 | O-RING | |
| 26 | S631-014004 | O-RING | |
| 27 | S631-024004 | O-RING | |
| 28 | S631-029004 | O-RING | |
| 29 | S621-011001 | O-RING | |
| 30 | S621-012001 | O-RING | |
| 31 | S621-018001 | O-RING | |
| 32 | S621-021001 | O-RING | |
| 33 | S109-080406 | BOLT-SOCKET | |
| 34 | S109-120556 | Bolt-Socket | |
| 35 | S015-060456 | BOLT-HEX | |
| 36 | S037-102026 | BOLT-W/WASHER | |
| 37 | S403-060006 | Washer-Plain | |
| 38 | X850-515100 | ELBOW-90 SWIVEL,ORFS | |
| 39 | X840-515151 | Tee-R/Type, Swivel, Orfs | |
| 40 | 31Q8-40520 | Sensor-Pressure | |
| 40 | 31Q4-40830 | SENSOR-PRESSURE | |
| 41 | 31Q6-20131 | EPPR VALVE-BREAKER | |
| 41 | 31Q6-20130 | Eppr Valve-Breaker | |
| 210 | EDH0427V-HD | Coil |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
