Каталог запасных частей к технике: Hyundai R180LC-9. PILOT HYD PIPING (BOTTOM 2)
5
6
7
7
8
10
11
11
12
13
13
14
15
16
17
18
19
20
20
20
21
35
35
39
41
42
43
44
45
45
46
47
48
48
50
53
54
55
56
57
57
58
59
60
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 5 | X400-042018 | Hose Assy-Synf, Orfs | |
| 6 | X410-042023 | Hose Assy-Orfs 0x45 | |
| 7 | X410-042034 | Hose Assy-Orfs 0x45 | |
| 8 | X410-042036 | Hose Assy-Orfs 0x45 | |
| 10 | 31N6-25060 | FILTER-LAST GUARD | |
| 11 | 31N6-25110 | ELBOW-90,LONG | |
| 12 | X500-110001 | CONNECTOR-ORFS | |
| 13 | X520-110001 | ELBOW-90,ORFS | |
| 14 | S037-102046 | Bolt-W/Washer | |
| 15 | S037-102526 | BOLT-W/WASHER | |
| 16 | S035-063046 | BOLT-W/WASHER | |
| 17 | S403-062006 | Washer-Plain | |
| 18 | 31E7-0312 | Clamp-Hose | |
| 19 | 31M6-51061 | SHIM | |
| 20 | S631-011004 | O-RING | |
| 21 | S621-011001 | O-RING | |
| 35 | S621-011001 | O-RING | |
| 39 | S621-011001 | O-RING | |
| 41 | X500-110001 | CONNECTOR-ORFS | |
| 42 | 31N6-25060 | FILTER-LAST GUARD | |
| 43 | X520-110001 | ELBOW-90,ORFS | |
| 44 | 31N6-25110 | ELBOW-90,LONG | |
| 45 | S631-011004 | O-RING | |
| 46 | S037-102522 | Bolt-W/Washer | |
| 47 | X840-515151 | Tee-R/Type, Swivel, Orfs | |
| 48 | X400-042021 | HOSE ASSY-SYNF,ORFS | |
| 50 | 21E6-30540 | Switch-Breaker | |
| 53 | X500-110001 | CONNECTOR-ORFS | |
| 54 | 31N6-25060 | FILTER-LAST GUARD | |
| 55 | X520-110001 | ELBOW-90,ORFS | |
| 56 | 31N6-25110 | ELBOW-90,LONG | |
| 57 | S631-011004 | O-RING | |
| 58 | S037-102522 | Bolt-W/Washer | |
| 59 | 21NB-00200 | Harness-Ext | |
| 60 | X840-515151 | Tee-R/Type, Swivel, Orfs |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
