Каталог запасных частей к технике: Hyundai R180LC-9. MAIN PUMP
MainPumpUnit
XJBN-01780
XJBN-00801
XJBN-00800
XJBN-01048
31Q5-10010
XJBN-01572
XJBN-01047
111
113
116
123
124
124
127
141
151
152
153
156
157
211
212
214
251
261
271
271
312
313
314
326
401
401
406
406
414
466
467
467
468
490
531
532
534
535
548
702
702
710
710
711
711
717
717
719
719
724
724
725
725
727
727
728
728
728
732
732
774
774
789
789
792
792
808
808
824
885
886
886
886
901
953
954
981
983
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| MainPumpUnit | MainPumpUnit | Main Pump Unit | |
| XJBN-01780 | XJBN-01780 | Seal kit | |
| XJBN-00801 | XJBN-00801 | Tilting Pin Sub Assy | |
| XJBN-00800 | XJBN-00800 | Swash Plate Sub Assy | |
| XJBN-01048 | XJBN-01048 | Cylinder Sub Assy-Rh | |
| 31Q5-10010 | 31Q5-10010 | Main Pump | |
| XJBN-01572 | XJBN-01572 | Piston Sub Assy | |
| XJBN-01047 | XJBN-01047 | Cylinder Sub Assy-Lh | |
| 111 | XJBN-00802 | Shaft(F)-Drive | |
| 113 | XJBN-00803 | Shaft(R)-Drive | |
| 116 | XJBN-00804 | Gear-1st | |
| 123 | XJBN-00429 | Bearing-Roller | |
| 124 | XJBN-00805 | Bearing-Needle | |
| 127 | XJBN-00806 | Spacer-Bearing | |
| 141 | XJBN-00807 | Block-Cylinder | |
| 151 | XJBN-00425 | Piston | |
| 152 | XJBN-01278 | Shoe | |
| 153 | XJBN-00808 | Plate-Set | |
| 156 | XJBN-00422 | Bushing-Spherical | |
| 157 | XJBN-00421 | Spring-Cylinder | |
| 211 | XJBN-00420 | Plate-Shoe | |
| 212 | XJBN-00419 | Plate-Swash | |
| 214 | XJBN-00418 | Bushing-Tilting | |
| 251 | XJBN-00417 | Support | |
| 261 | XJBN-00809 | Cover-Fr | |
| 271 | XJBN-01046 | Casing-Pump | |
| 312 | XJBN-00812 | Block-Valve | |
| 313 | XJBN-01045 | Plate(R)-Valve | |
| 314 | XJBN-01044 | Plate(L)-Valve | |
| 326 | XJBN-00937 | Cover | |
| 401 | XJBN-00411 | Screw | |
| 406 | XJBN-00813 | Screw | |
| 414 | XJBN-00160 | Screw-Socket | |
| 466 | XJBN-00030 | PLUG | |
| 467 | XJBN-00487 | Plug | |
| 468 | XJBN-00814 | PLUG | |
| 490 | XJBN-00032 | PLUG | |
| 531 | XJBN-00815 | Pin-Tilting | |
| 532 | XJBN-00407 | Piston-Servo | |
| 534 | XJBN-00816 | Stopper | |
| 535 | XJBN-00405 | Stopper | |
| 548 | XJBN-00360 | PIN-FEED BACK | |
| 702 | XJBN-00817 | O-Ring | |
| 710 | XJBN-00387 | O-Ring | |
| 711 | XJBN-00095 | O-Ring | |
| 717 | XJBN-00818 | O-Ring | |
| 719 | XJBN-00819 | O-Ring | |
| 724 | XJBN-00044 | O-RING | |
| 725 | XJBN-00045 | O-RING | |
| 727 | XJBN-00233 | O-RING | |
| 728 | XJBN-00097 | O-RING | |
| 732 | XJBN-00820 | O-RING | |
| 735 | XJBN-00280 | O-RING | |
| 774 | XJBN-01029 | Seal-Oil | |
| 789 | XJBN-00476 | Ring-Back Up | |
| 792 | XJBN-00454 | Ring Back-Up | |
| 808 | XJBN-00101 | Nut-Hex | |
| 824 | XJBN-00821 | Ring-Snap | |
| 885 | XJBN-00394 | Pin-Valve Plate | |
| 886 | XJBN-00054 | PIN-SPRING | |
| 901 | XJBN-00104 | Bolt-Eye | |
| 953 | XJBN-00105 | Screw-Set | |
| 954 | XJBN-00392 | Screw-Set | |
| 981 | XJBN-00156 | NAME PLATE | |
| 983 | XJBN-00455 | Pin |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
