Каталог запасных частей к технике: Hyundai R180LC-9. HEATER UNIT (SEMI AUTO)
11Q6-90121
11Q6-90120
1
1
2
3
4
5
6
7
8
10
11
11
12
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
32
32
33
33
34
35
36
38
39
40
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 11Q6-90121 | 11Q6-90121 | Heater Unit | |
| 11Q6-90120 | 11Q6-90120 | Heater Unit | |
| 1 | AH002686 | CASE-UPPER,INTAKE | |
| 1 | AH002585 | Case-Upper Htr & Evap | |
| 2 | AM13200100-0 | CASE-LOWER,INTAKE | |
| 3 | AM47000200-2 | DAMPER ASSY-INTAKE | |
| 4 | AM70003600-3 | SEAL-FILTER,FRESH | |
| 5 | 11N6-90770 | AIR FILTER-REFRESH | |
| 6 | AH54100100-3 | LEVER-DEF | |
| 7 | 3AH0705 | ROD-CLAMP | |
| 8 | 4AH0688 | CLIP-CASE | |
| 10 | 11Q6-90570 | MOTOR ACT-INTAKE | |
| 11 | AM52300100-4 | Rod-Intake | |
| 11 | AM52300100-3 | ROD-INTAKE | |
| 12 | AH002402 | HVAC CASE-LOW | |
| 16 | AH002401 | HVAC CASE-UPP | |
| 17 | 4AH0643 | HOLDER-WIRE | |
| 18 | 11N6-90820 | RELAY | |
| 19 | AH000865 | SCREW | |
| 20 | AH001160 | VLAVE-WATER | |
| 21 | AH000559 | ROD-TEMP | |
| 22 | AH100656 | MOTOR ACT ASSY-TEMP | |
| 23 | AH001287 | HOSE-INLET,WATER | |
| 24 | AH002411 | HOSE-INLET,WATER | |
| 25 | AH002412 | HOSE-OUTLET,WATER | |
| 26 | AH001853 | CLAMP-WATER HOSE | |
| 27 | 11Q6-90540 | HEATER SET-RAD | |
| 28 | AH002410 | PIPE-INLET/OUTLET | |
| 29 | AH002403 | CASE-BLOWER,LH | |
| 30 | AH002404 | CASE-BLOWER,RH | |
| 31 | AH002407 | DOOR ASSY-VENT | |
| 32 | AW80000303-3 | Seal-Sponge A | |
| 32 | AW800003-3 | SEAL-SPONGE A | |
| 33 | AW800003-4 | Seal-Sponge B | |
| 33 | AW80000304-3 | Seal-Sponge B | |
| 34 | 11N6-90700 | FAN & MOTOR | |
| 35 | 11Q6-90530 | FET | |
| 36 | 11Q6-90520 | MOTOR ACT ASSY-VENT DF | |
| 38 | 11Q6-90610 | Wiring Assy-Satc | |
| 39 | 11Q6-90502 | APTC ASSY | |
| 40 | AH000314 | CLAMP-H/RAD PIPE |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
