51Q5-51800
51Q5-51900
1
2
3
4
5
5
5
6
6
6
7
8
8
9
110
110
110
120
130
130
Позиция на иллюстрации
Заводской номер детали
Название детали
51Q5-51800
51Q5-51800
Dozer Blade Assy
51Q5-51900
51Q5-51900
Dozer Blade Assy
1
51Q5-51700
Dozer Blade Assy
2
53N5-51300GG
Pin Assy
3
51Q5-51310
Pin Assy
4
51Q5-51320
Pin Assy
5
53N5-51330GG
Plate
6
S037-102556
BOLT-W/WASHER
7
S651-810002
NIPPLE-GREASE
8
S391-070120
Shim-Round
9
S391-080130
Shim-Round
110
51Q5-51810
Dozer Blade Wa
110
51Q5-51910
Dozer Blade Wa
110
51Q5-51710
Dozer Blade Wa
120
61Q6-05020
Bushing
130
Y020-080011
Seal-Dust, Dli, Kpu
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
