Каталог запасных частей к технике: Hyundai R180LC-9. CAB MOUNTING
2
2
3
4
5
6
6
6
7
8
9
12
12
12
13
14
16
19
20
21
22
23
24
24
28
29
30
31
51
51
52
52
310
320
320
330
330
340
340
350
360
360
360
370
380
390
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 2 | 71Q6-02704 | Handrail | |
| 2 | 71Q6-02705 | HANDRAIL | |
| 3 | 71Q6-04301 | RAIN GUARD ASSY | |
| 4 | 71Q6-04501 | NON SLIP PLATE | |
| 5 | 71N8-47001GG | MIRROR & STAY ASSY-LH | |
| 6 | 71Q6-04511 | BOSS | |
| 6 | 75Q4-03010 | CAP | |
| 7 | S441-300006 | WASHER-HARDENED | |
| 8 | S411-300006 | WASHER-SPRING | |
| 9 | S017-30110D | BOLT-HEX | |
| 12 | S037-102526 | BOLT-W/WASHER | |
| 13 | S015-060156 | BOLT-HEX | |
| 14 | S037-123526 | BOLT-W/WASHER | |
| 16 | 71Q6-06360 | HANDRAIL ASSY | |
| 19 | S403-10100B | WASHER-PLAIN | |
| 20 | S411-100006 | WASHER-SPRING | |
| 21 | S109-100256 | BOLT-SOCKET | |
| 22 | 71Q6-01590 | SPONGE | |
| 23 | S403-10500B | WASHER-PLAIN | |
| 24 | 71Q6-01471 | Handrail | |
| 24 | 71Q6-01472 | HANDRAIL | |
| 25 | 71Q6-06410 | Stay-Mirror | |
| 25 | 71Q6-06411 | Stay-Mirror | |
| 26 | 71Q4-47100 | Mirror | |
| 27 | S037-122526 | BOLT-W/WASHER | |
| 28 | S037-123026 | BOLT-W/WASHER | |
| 29 | S403-06500B | WASHER-PLAIN | |
| 30 | 91Q6-01282 | Plate-Rops | |
| 31 | 91EK-12010 | RIVET | |
| 51 | 71N8-47101 | MIRROR | |
| 52 | 71N8-47200GG | STAY ASSY | |
| 310 | 71Q6-04311 | RAIN GUARD | |
| 320 | 71Q6-04320 | Bracket-Lh | |
| 320 | 71Q6-04321 | BRACKET-LH | |
| 330 | 71Q6-04330 | Bracket-Rh | |
| 330 | 71Q6-04331 | BRACKET-RH | |
| 340 | 71Q6-04340 | Bracket Wa | |
| 340 | 71Q6-04341 | BRACKET WA | |
| 350 | S772-008800 | WEATHER STRIP | |
| 360 | S132-061526 | Screw-W/Washer | |
| 360 | S035-062066 | BOLT-W/WASHER | |
| 370 | S205-061006 | Nut-Hex | |
| 380 | S015-060156 | BOLT-HEX | |
| 390 | S403-06500B | WASHER-PLAIN |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
