66N5-32000GG
1
2
3
4
5
6
7
8
9
10
11
12
13
14
110
Позиция на иллюстрации
Заводской номер детали
Название детали
66N5-32000GG
66N5-32000GG
Bucket Assy
E161-3035-S
E161-3035-S
Tooth Pin Kit
1
66N5-32010GG
Bucket Wa
2
61E3-3033GG
Side Cutter-Lh
3
61E3-3034GG
Side Cutter-Rh
4
61N6-31310GG
Point-Tooth
5
E161-3035
Pin-Tooth
6
61EK-11260
Bushing
7
61N5-31360GG
Plate-Cover
8
61EK-31410
Shim
9
S017-16050D
BOLT-HEX
10
S017-20055D
Bolt-Hex
11
S205-201006
Nut-Hex
12
S411-160006
WASHER-SPRING
13
61E5-11150
WASHER-LOCK
14
S411-200006
Washer-Spring
110
61N6-31320
Adapter-Tooth
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
