Каталог запасных частей к технике: Hyundai R170W-9S. POWER TRAIN MOUNTING

Тип техники

Марка

Модель

Схема

1

10

10-3

11

11

11

11

12

12

13

14

14

15

16

17

17

17

17

18

18

18

18

19

19

2

20

21

21

22

22

23

23

24

25

26

26

27

28

29

29-3

3

30

31

32

33

33

34

40

40-11

40-12

40-13

40-2

41

41

42

43

44

6

8

9

Позиция на иллюстрации	Заводской номер детали		Название детали
1	81N5-40010		AXLE-FRONT
1	81N5-41010		AXLE-FRONT
10	81Q5-40222		SUPPORT-O/CYLINDER
10-3	S652-810002		Nipple-Grease
11	S441-200006		WASHER-HARDENED
12	S441-220006		Washer-Hardened
13	S017-20045D		Bolt-Hex
14	S411-200006		Washer-Spring
15	S017-20170D		BOLT-HEX
16	S205-20100B		NUT-HEX
17	81E4-3007-DA		Nut-Hex
18	S411-100006		WASHER-SPRING
19	S018-22075D		Bolt-Hex
2	81N5-40020		AXLE-REAR
2	81N5-41020		AXLE-REAR
20	81Q4-40450		Seal-Grease
20	E181-3001		SEAL-GREASE
21	S017-16035D		Bolt-Hex
22	S411-160006		WASHER-SPRING
23	S651-810008		Nipple-Grease
24	S017-120256		Bolt-Hex
25	S411-120006		WASHER-SPRING
26	81E3-30071-DA		Bolt-Hex
27	S384-207225		Plate-Lock
28	S018-20130D		BOLT-HEX
29	81Q5-40232		SUPPORT-O/CYLINDER
29-3	S652-810002		Nipple-Grease
3	81N5-40040		TRANSMISSION
30	P933-042016		Hose Assy-Orfs 0x90
31	31N4-40180		Connector
32	31Q5-43420		CONNECTOR
33	S621-011001		O-RING
34	S017-20050D		BOLT-HEX
40	81N5-50100GG		Tire & Wheel Assy
40	81N5-50200GG		Tire & Wheel Assy
40	81N5-50201GG		TIRE & WHEEL ASSY
40-1	81E4-20200		Tire Assy
40-1	81E4-21020		Tire
40-11	81E4-2001		Tire
40-12	81E4-2002		Tire
40-13	81E4-2003		Flap
40-2	81N5-50010GG		Wheel Wa
41	81N5-50061		Ring-Stone Register
42	81Q5-30111		GUARD-TRANSMISSION
43	S017-16030D		Bolt-Hex
44	S441-160006		WASHER-HARDENED
45	S411-160006		WASHER-SPRING
6	81Q5-32061		BRACKET-TRANSMISSION
8	81Q5-40211		PIN-PIVOT
9	81E3-0003		Bushing
40-1	81E4-20200H		Tire Assy
40-1	81E4-20200S		Tire Assy

Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
