Позиция на иллюстрации
Заводской номер детали
Название детали
1
21Q5-17200
HARNESS-ENGINE
1
21Q5-16201
HARNESS-ENGINE
1-1
21EA-50550
Diode
10
21EA-50260
PACKING-TEMP SW
11
21E7-0606
PLATE-CONNECTOR
15
S035-061526
BOLT-W/WASHER
16
S037-102026
BOLT-W/WASHER
17
S552-035146
Clamp-Band
18
21N5-10100
Cable
19
S035-081526
BOLT-W/WASHER
20
S543-160002
CLAMP-TUBE
21
S593-000902
CLIP-HARNESS
22
S285-06100B
Nut-Flanged
23
S205-05100B
Nut-Hex
24
S037-122026
BOLT-W/WASHER
25
S411-050006
WASHER-SPRING
26
21N4-01130
PLATE-CLIP
27
21Q8-16420
HARNESS-PUMP PS
3
21N5-10110
CABLE
4
24L1-30720
Strap-Earth
5
21N8-42050
RELAY-HEATER
6
21N5-10040
PLATE
7
21EN-40100
SENDER-TEMP
8
21EE-20100
ADAPTER-TEMP SENDER
9
P392-160000
Washer-Copper
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
