Позиция на иллюстрации	Заводской номер детали	Название детали
1	91Q5-00300	DECAL KIT
1-1	91E1-27110	DECAL-L/EMISSION ENG
1-10	91N6-07340	Decal-Ideogram
1-10	92N6-07360	Decal-Ideogram
1-10	92N6-07431	Decal-Ideogram
1-11	92N6-07410	Decal-Swing Ideogram
1-12	92N6-07420	Decal-Steering Wheel
1-13	92N6-07510	Decal-Console Box Tilt
1-14	91N6-07131	DECAL-NO STEP
1-2	91N6-02120	DECAL-BATT ACCIDENT
1-3	91N6-01121	DECAL-RADIATOR CAP
1-4	91N6-03140	DECAL-FALLING
1-5	91N6-03111	DECAL-HYD OIL LUBRICAT
1-6	91N6-03130	DECAL-H/PRESS HOSE
1-7	92N6-07200	Decal-Cntl Ideogram
1-7	92N6-08200	Decal-Cntl Ideogram
1-7	92N6-07500	Decal-Cntl Ideogram
1-7	92N6-08500	Decal-Cntl Ideogram
1-8	92N6-07310	DECAL-SAFETY LEVER
1-9	91N6-07272	DECAL-AIRCON FILTER
2	91Q5-30106	DECAL KIT
2	91Q5-30107	DECAL KIT
2	91Q5-30108	DECAL KIT
2	91Q5-30109	DECAL KIT
2	91Q5-30110	DECAL KIT
2	91Q5-30111	DECAL KIT
2	91Q5-30112	DECAL KIT
2	91Q5-30113	DECAL KIT
2-1	91Q5-10060	DECAL-MODEL NAME
2-1	91Q5-10061	DECAL-MODEL NAME
2-1	91Q5-10062	DECAL-MODEL NAME
2-10	91N6-06110	Decal-Keep Clear-Att
2-11	91Q6-07010	DECAL-KEEP CLEAR,RR
2-12	91Q6-07021	DECAL-KEEP CLEAR,SIDE
2-13	92N6-03100	Decal-Hyd Oil Level
2-14	92N6-07140	Decal-Transporting
2-15	91N6-03121	DECAL-R/GEAR GREASE
2-16	91N6-22130	DECAL-NOISE LWA/103DB
2-17	91MJ-01140	Decal-Fueling
2-18	91N6-04140	Decal-Lifting Eye
2-19	92Q6-07350	Decal-Swing Lock
2-2	91Q6-07112	Decal-Robex Logo
2-20	91N6-07400	DECAL-M/CNTL CAB
2-21	91N6-07410	DECAL-M/CNTL PATTERN
2-22	91N6-03200	DECAL-ACCUMULATOR
2-23	91Q6-07510	DECAL-BAND,CAB FR
2-24	91Q6-07520	DECAL-BAND,CAB RR
2-25	91Q4-07530	Decal-S/Door Band,Lh
2-26	91Q4-07611	Decal-Tool Box Band
2-27	91Q4-07620	Decal-Tank Band
2-28	91Q4-07630	Decal-S/Door Band,Rh
2-29	91Q4-07370	Decal-Cabin Rh Pillar
2-3	91N6-23100	Decal-Hyundai Logo
2-30	91Q6-03210	DECAL-RCV L/PATTERN
2-31	91Q4-07020	Decal-Reflecting
2-31	91Q4-07020	Decal-Reflecting
2-32	91Q6-03220	Decal-Swing Bearing
2-32	91Q6-03240	DECAL-SWING BEARING
2-33	91MJ-02110	Decal-Batt Position
2-34	91Q4-02200	DECAL-BEACON LAMP
2-34	91Q4-02200	DECAL-BEACON LAMP
2-35	91Q6-03230	DECAL-FUEL SHUT OFF
2-35	91Q6-03230	DECAL-FUEL SHUT OFF
2-36	91Q4-07180	Decal-Water Separator
2-36	91Q4-07920	DECAL-CAUTION(W/S,T/C)
2-36	91Q4-07180	Decal-Water Separator
2-36	91Q4-07920	DECAL-CAUTION(W/S,T/C)
2-37	91Q4-15860	DECAL-MCU CONNECTOR
2-37	91Q4-15860	DECAL-MCU CONNECTOR
2-38	91N6-07280	Decal-Hammer
2-38	91N6-07280	Decal-Hammer
2-38	91Q6-07280	DECAL-HAMMER
2-39	91Q6-01281	Decal-Rops Cabin
2-39	91Q6-01281	Decal-Rops Cabin
2-4	91N6-26160	Decal-Hyundai Logo
2-40	91Q6-07260	DECAL-SAFETY RR WIN
2-5	91Q5-04101	DECAL-LIFTING CHART KIT
2-6	91Q5-10721	DECAL-S/INSTRUCTION
2-6	91Q5-10722	DECAL-S/INSTRUCTION
2-6	91Q5-10723	DECAL-S/INSTRUCTION
2-6	91Q5-10724	DECAL-S/INSTRUCTION
2-7	91Q6-07330	DECAL-LOCKING CLAMP
2-8	91N6-07390	Decal-Turbocharger
2-9	91LB-01350	DECAL-ELECTRIC WELDING
20	91Q4-00092	Decal Kit-A/S
20	91Q4-00093	DECAL KIT-A/S
20-1	91N6-01102	DECAL-A/CLEANER FILTER
20-2	91N6-01111	DECAL-TURBO COVER
20-3	91N6-07121	DECAL-SHEARING
20-4	91N6-07131	DECAL-NO STEP
20-5	91N6-07112	DECAL-STAY FIX
20-6	91Q6-07250	DECAL-SAFETY FR WIN
20-7	91N6-07261	Decal-Alternate Exit
3	91LM-14110	PIN PLATE
3	91LM-14110	PIN PLATE
3	91LM-14130	PIN PLATE
4	91EK-12010	RIVET
5	91N6-01280	FOPS FOG PLATE
6	91EK-12010	RIVET
