Каталог запасных частей к технике: Hyundai R170W-7. TRAVEL MOTOR (2/2, -#0196)
2-12
32
1-1
1-1
1-2
1-2
1-3
1-3
1-4
1-4
1-5
1-5
1-7
1-7
1-9
1-9
1-14
1-14
1-15
1-15
1-16
1-16
1-17
1-17
1-19
1-19
1-20
1-20
1-21
1-21
1-22
1-22
1-23
1-23
1-29
1-29
2
2
2-1
2-1
2-2
2-2
2-10
2-10
2-11
2-11
3
3
4
4
5
5
7
7
8
8
15
15
16
16
19
19
20
20
20
20
21
21
22
22
23
23
24
24
26
26
28
28
29
29
33
33
34
34
34
34
50
50
50
50
XJDD-00683
XJDD-00683
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 2-12 | ZGAR-00343 | Screw-Locking | |
| 32 | ZGAR-00330 | Pin-D/Break Off | |
| ZGAR-00400 | ZGAR-00400 | Control | |
| 1 | ZGAR-00313 | Control Part | |
| 1-1 | ZGAR-00334 | Housing-Control | |
| 1-2 | ZGAR-00335 | Bushing-Control | |
| 1-3 | ZGAR-00336 | Piston-Control | |
| 1-4 | ZGAR-00337 | Bushing-Adjusting | |
| 1-5 | ZGAR-00338 | Collar-Spring | |
| 1-7 | ZGAR-00339 | Spring-Pressure | |
| 1-9 | ZGAR-00340 | Spring-Pressure | |
| 1-14 | XJDD-00271 | O-Ring | |
| 1-15 | ZGAR-00342 | Screw-Socket Head | |
| 1-16 | ZGAR-00343 | Screw-Locking | |
| 1-17 | ZGAR-00344 | Ring-Retaining | |
| 1-19 | ZGAR-00345 | Pin-Threaded | |
| 1-20 | ZGAR-00346 | Pin-Cylinder | |
| 1-21 | XJDD-00276 | Nut-Seal Lock | |
| 1-22 | ZGAR-00348 | Pin-D/Break Off | |
| 1-23 | ZGAR-00330 | Pin-D/Break Off | |
| 1-29 | ZGAR-00349 | Disc-Retaining | |
| 2 | ZGAR-00436 | Cover | |
| 2-1 | ZGAR-00449 | Cover | |
| 2-2 | ZGAR-00351 | Screw-Throttle | |
| 2-10 | ZGAR-00450 | Socket-Head Screw | |
| 2-11 | XJDD-00284 | O-Ring | |
| 3 | ZGAR-00437 | Port Plate | |
| 4 | ZGAR-00438 | Piston-Positioning | |
| 5 | ZGAR-00439 | Trunnion-Positioning | |
| 7 | ZGAR-00440 | Piston | |
| 8 | ZGAR-00441 | Threaded Pin | |
| 15 | ZGAR-00442 | Screw-Socket Head | |
| 16 | ZGAR-00443 | Screw-Socket Head | |
| 19 | XJDD-00620 | O-Ring | |
| 20 | XJDD-00258 | O-Ring | |
| 21 | XJDD-00259 | O-Ring | |
| 22 | XJDD-00329 | Ring-Back Up | |
| 23 | ZGAR-00445 | Screw-Socket Head | |
| 24 | ZGAR-00446 | Ring-Square | |
| 26 | ZGAR-00447 | Pin-Cylinder | |
| 28 | ZGAR-00328 | Pin-D/Break Off | |
| 29 | ZGAR-00329 | Plug | |
| 33 | ZGAR-00448 | Screw-Locking | |
| 34 | ZGAR-00332 | Screw-Locking | |
| 50 | ZGAR-00333 | Relief Valve | |
| XJDD-00683 | XJDD-00683 | Seal Kit |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
