1
3
4
5
6
7
8
9
11
12
13
14
15
15
16
16
17
18
18
20
21
22
23
24
25
26
26
27
29
Позиция на иллюстрации
Заводской номер детали
Название детали
81EK-00011
81EK-00011
STEERING VALVE
YUBS-00333
YUBS-00333
Seal Kit
YUBS-00068
YUBS-00068
Seal Kit
Seal-Dust
Seal-Dust
Seal-Dust
81EK-00010
81EK-00010
Steering Valve
1
YUBS-00001
Seal-Dust
3
YUBS-00002
Ball
4
YUBS-00003
Bushing-Thread
5
YUBS-00056
O-Ring
6
YUBS-00057
Ring-King
7
YUBS-00005
Bearing Assy
8
YUBS-00006
Ring
9
YUBS-00007
Pin-Cross
11
YUBS-00008
Shaft-Cardan
12
YUBS-00058
Spring Set
13
YUBS-00010
O-Ring
14
YUBS-00011
Plate-Distributor
15
YUBS-00059
Set-Gear Wheel
16
YUBS-00013
O-Ring
17
YUBS-00014
Cover-End
18
YUBS-00015
Washer
20
YUBS-00060
Screw-Pin
21
YUBS-00061
Screw
22
YUBS-00062
Plate-Name
23
YUBS-00037
Screw-Drive
24
YUBS-00063
Relief Valve Assy
25
YUBS-00064
Spring-Wire
26
YUBS-00065
Vlv-Shock,Complete
27
YUBS-00066
Ball
29
YUBS-00067
Bushing-W/Pin
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
