Каталог запасных частей к технике: Hyundai R170W-7. POWER TRAIN MOUNTING

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
1
2
2
3
3
6
6
6
8
8
9
9
10
10
11
11
11
12
12
13
13
14
15
16
17
17
17
17
18
18
18
18
19
19
20
21
22
23
24
25
26
26
28
28
29
30
30
30
300
300
30-1
30-2
30-3
30-4
30-4
30-4
31
31
31
32
32
32
32-1
32-4
Позиция на иллюстрации Заводской номер детали Название детали
1 81EK-30010 Axle-Front
1 81N5-40010 AXLE-FRONT
2 81EK-30020 Axle-Rear
2 81N5-40020 AXLE-REAR
3 81EA-30031 Transmission
3 81N5-40030 Transmission
6 81EK-30060 Bracket
6 81N5-30060 Bracket
6 81N5-30060BG Bracket
8 81EK-40210 Pin-Pivot
8 81EK-40210BG Pin-Pivot
9 81E3-0003 Bushing
10 81EK-40220 Support-Oscil Cyl
10 81EK-40220BG Support-Oscil Cyl
11 S441-200006 WASHER-HARDENED
12 S441-220006 Washer-Hardened
13 S017-20050D BOLT-HEX
14 S411-200006 Washer-Spring
15 S018-20170D Bolt-Hex
16 S206-20100B Nut-Hex
17 81E4-3007-DA Nut-Hex
18 S411-100006 WASHER-SPRING
19 S018-22075D Bolt-Hex
20 E181-3001 SEAL-GREASE
21 S017-16035D Bolt-Hex
22 S411-160006 WASHER-SPRING
23 S652-810002 Nipple-Grease
24 S017-120256 Bolt-Hex
25 S411-120006 WASHER-SPRING
26 81E3-30071-DA Bolt-Hex
28 51E3-3164 Plate-Lock
28 51E3-3164BG Plate-Lock
29 S018-20130D BOLT-HEX
30 81E4-20100 Tire & Wheel Assy
30 81N5-50100 Tire & Wheel Assy
30 81N5-50100BG Tire & Wheel Assy
300 81E4-20200 Tire Assy
300 81E4-20200H Tire Assy
30-1 81E4-2001 Tire
30-2 81E4-2002 Tire
30-3 81E4-2003 Flap
30-4 81E4-20042 Wheel Wa
30-4 81N5-50010 Wheel Wa
30-4 81N5-50010BG Wheel Wa
31 82E4-2005 Ring-Stone Resister
31 81N5-50060 Ring-Stone Resister
31 81N5-50061 Ring-Stone Register
32 81E4-21010 Tire & Wheel Assy
32 81N5-50200 Tire & Wheel Assy
32 81N5-50200BG Tire & Wheel Assy
32-1 81E4-21020 Tire
32-4 81E4-20080 Wheel
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
