Каталог запасных частей к технике: Hyundai R170W-7. POWER TRAIN HYD PIPING 2 (-#0978)
6
10
10
11
13
13
13
14
14
18
18
20
20
20
20
21
22
22
26
27
27
28
28
28
30
30
31
31
32
33
33
36
36
36
38
41
42
48
49
50
51
51
52
54
54
54
54
54
56
56
56
56
56
56
56
56
56
56
56
57
57
57
57
57
57
58
58
58
58
58
58
66
68
68
69
70
73
73
74
74
74
75
75
76
76
78
78
79
79
80
80
80
80
80
81
81
81
81
81
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| PowerTrainHydPiping | PowerTrainHydPiping | Power Train Hyd Piping | |
| 6 | 81L1-0003 | Accumulator | |
| 10 | 31LF-00500 | Switch-Pressure | |
| 10 | 31L1-0095 | Switch-Pressure | |
| 11 | 31N4-30150 | Switch-Pressure | |
| 13 | 31EK-11130 | COUPLING-SCREW | |
| 14 | 31EK-20100 | Filter-Last Guard | |
| 14 | 31N6-25060 | FILTER-LAST GUARD | |
| 18 | 34EA-20340 | Connector | |
| 18 | 31N6-30110 | Connector | |
| 20 | P010-110002 | Connector | |
| 20 | X500-110001 | CONNECTOR-ORFS | |
| 20 | X500-110002 | CONNECTOR-ORFS | |
| 21 | P010-110003 | Connector | |
| 22 | P010-110013 | Connector | |
| 22 | X500-110013 | CONNECTOR-ORFS | |
| 26 | X511-108534 | Connector-Long, Orfs | |
| 27 | P020-110001 | ELBOW-90 | |
| 27 | X520-110001 | ELBOW-90,ORFS | |
| 28 | P020-110002 | Elbow-90 | |
| 28 | X520-110002 | ELBOW-90,ORFS | |
| 30 | 31L7-20430 | Elbow-90 | |
| 30 | 31N5-30030 | Elbow-90,Orfs,Long | |
| 31 | X520-110003 | ELBOW-90,ORFS | |
| 32 | 31N8-40310 | Elbow-90,Orfs,Long | |
| 33 | 31N4-22110 | Tee | |
| 33 | 31N5-30040 | Tee | |
| 36 | P220-110102 | Plug-Hex | |
| 38 | P220-110104 | Plug-Hex | |
| 41 | P392-220000 | WASHER-COPPER | |
| 42 | S017-100902 | Bolt-Hex | |
| 48 | S205-101002 | NUT-HEX | |
| 49 | S403-102002 | Washer-Plain | |
| 50 | S411-100002 | WASHER-SPRING | |
| 51 | S551-050203 | Clamp-Band | |
| 52 | S611-009001 | O-Ring | |
| 54 | S621-014001 | O-RING | |
| 56 | S631-011004 | O-RING | |
| 57 | S631-014004 | O-RING | |
| 58 | S631-018004 | O-RING | |
| 66 | S035-062026 | BOLT-W/WASHER | |
| 68 | P910-082053 | Hose Assy-Orfs 0x0 | |
| 68 | P910-082050 | Hose Assy-Orfs 0x0 | |
| 69 | P920-082023 | Hose Assy-Orfs 0x45 | |
| 70 | P930-082026 | Hose Assy-Orfs 0x90 | |
| 73 | P860-042050 | Hose Assy-Syn 0x90 | |
| 73 | X420-042050 | Hose Assy-Orfs 0x90 | |
| 74 | P840-062034 | Hose Assy-Syn Thd | |
| 74 | X400-062036 | HOSE ASSY-SYNF,ORFS | |
| 74 | P910-062036 | Hose Assy-Orfs 0x0 | |
| 75 | P860-062041 | Hose Assy-Syn 0x90 | |
| 75 | X420-062041 | Hose Assy-Orfs 0x90 | |
| 76 | P860-062049 | Hose Assy-Syn 0x90 | |
| 76 | X420-062049 | Hose Assy-Orfs 0x90 | |
| 78 | P860-042044 | Hose Assy-Syn 0x90 | |
| 78 | X420-042044 | Hose Assy-Orfs 0x90 | |
| 79 | P860-042079 | Hose Assy-Syn 0x90 | |
| 79 | X420-042079 | Hose Assy-Orfs 0x90 | |
| 80 | S621-011001 | O-RING | |
| 81 | S621-012001 | O-RING |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
