Позиция на иллюстрации
Заводской номер детали
Название детали
PowerTrainHydPiping
PowerTrainHydPiping
Power Train Hyd Piping
6
81L1-0003
Accumulator
7
31EC-02190
Accumulator
10
31LF-00500
Switch-Pressure
13
31EK-11130
COUPLING-SCREW
16
X420-042044
Hose Assy-Orfs 0x90
17
X840-535153
Tee-R/Type,Swivel,Orfs
18
31N6-30110
Connector
20
X500-110001
CONNECTOR-ORFS
23
X500-110013
CONNECTOR-ORFS
26
31N6-30120
Connector
26
31Q6-30160
Connector-Long
31
31N4-31280
Connector
33
31N5-30040
Tee
36
P220-110102
Plug-Hex
38
P220-110104
Plug-Hex
42
S017-100906
Bolt-Hex
48
S205-101006
NUT-HEX
49
S403-102006
WASHER-PLAIN
50
S411-100006
WASHER-SPRING
51
S551-050203
Clamp-Band
54
Y161-016001
O-Ring
56
S631-011004
O-RING
57
S631-014004
O-RING
58
S631-018004
O-RING
66
P930-062047
Hose Assy-Orfs 0x90
66
P910-064047
Hose Assy-Orfs 0x0
70
P930-082026
Hose Assy-Orfs 0x90
73
X420-042050
Hose Assy-Orfs 0x90
74
P930-082024
Hose Assy-Orfs 0x90
75
X420-062041
Hose Assy-Orfs 0x90
76
X420-062049
Hose Assy-Orfs 0x90
78
S621-014001
O-RING
79
X420-042079
Hose Assy-Orfs 0x90
80
S621-011001
O-RING
81
S621-012001
O-RING
85
31E3-3187
Accumulator
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
Дополнительная информация
×
Название:
Номер:
Примечание:
