Каталог запасных частей к технике: Hyundai R170W-7. POWER TRAIN HYD PIPING 1 (#0979-)
44
1
1
2
3
4
4
8
11
12
13
15
19
20
21
21
22
24
24
25
25
27
28
29
30
30
31
31
32
33
34
34
34
35
37
39
40
41
43
43
45
47
51
51
53
54
54
54
54
54
55
56
56
56
56
57
57
57
57
58
58
58
58
59
59
60
61
62
62
62
62
63
63
63
64
64
64
65
67
67
68
68
69
69
69
69
69
69
71
72
72
77
77
78
78
80
80
80
80
80
81
81
81
81
81
81
81
81
81
82
83
84
85
86
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 44 | S037-122522 | Bolt-W/Washer | |
| PowerTrainHydPiping | PowerTrainHydPiping | Power Train Hyd Piping | |
| 1 | 31N5-30020 | Power Train Pump | |
| 1 | 31Q5-30020 | Power Train Pump | |
| 1-1 | ZTAV-00035 | Seal Kit | |
| 1-1 | XKAG-00017 | Seal Kit | |
| 2 | 31N6-24120 | Tee-Shuttle | |
| 3 | 31EM-20110 | Adapter | |
| 4 | 31N4-30130 | Tcv Valve | |
| 8 | X520-110012 | ELBOW-90,ORFS | |
| 11 | 31N4-30150 | Switch-Pressure | |
| 12 | 31N4-31291 | Bracket-Tcv | |
| 13 | 31EK-11130 | COUPLING-SCREW | |
| 15 | X400-042042 | Hose Assy-Synflex, Orfs | |
| 19 | X500-110003 | CONNECTOR-ORFS | |
| 20 | X500-110001 | CONNECTOR-ORFS | |
| 21 | X500-210005 | Connector-Orfs | |
| 22 | X500-210006 | Connector-Orfs | |
| 24 | X420-042014 | Hose Assy-Orfs 0x90 | |
| 24 | P930-042014 | Hose Assy-Orfs 0x90 | |
| 25 | X420-042012 | Hose Assy-Orfs 0x90 | |
| 25 | P930-042012 | HOSE ASSY-ORFS 0X90 | |
| 27 | X810-085253 | Tee-B/Type,Orfs | |
| 28 | X520-110002 | ELBOW-90,ORFS | |
| 29 | X820-085253 | Tee-R/Type,Orfs | |
| 30 | X840-525152 | TEE-R/TYPE,SWIVEL,ORFS | |
| 31 | 31N4-31280 | Connector | |
| 32 | 31N8-40310 | Elbow-90,Orfs,Long | |
| 33 | 31N5-30040 | Tee | |
| 34 | P173-080101 | Flange-Split | |
| 34 | 31N4-30290 | Flange-Pipe | |
| 35 | 31N4-30220 | Flange | |
| 37 | P220-110103 | PLUG-HEX | |
| 39 | P392-120000 | Washer-Copper | |
| 40 | S109-080456 | Bolt-Socket | |
| 41 | S109-080556 | Bolt-Socket | |
| 43 | S037-122526 | BOLT-W/WASHER | |
| 45 | S109-080256 | BOLT-SOCKET | |
| 47 | S109-060756 | Bolt-Socket | |
| 51 | S551-050203 | Clamp-Band | |
| 53 | Y161-018001 | O-Ring | |
| 54 | Y161-016001 | O-Ring | |
| 55 | S621-018001 | O-RING | |
| 56 | S631-011004 | O-RING | |
| 57 | S631-014004 | O-RING | |
| 58 | S631-018004 | O-RING | |
| 59 | Y171-015004 | O-Ring | |
| 59 | S631-022001 | O-Ring | |
| 60 | S631-025004 | O-Ring | |
| 61 | 31N4-30211 | Hose Assy | |
| 62 | P950-084363 | Hose Assy-Orfs,Flg 0x45 | |
| 62 | P920-087063 | Hose Assy-Orfs 0x45 | |
| 63 | P950-084382 | Hose Assy-Orfs,Flg 0x45 | |
| 63 | P920-087082 | Hose Assy-Orfs 0x45 | |
| 64 | S621-021001 | O-RING | |
| 65 | X511-106523 | Connector-Long, Orfs | |
| 67 | P930-066036 | Hose Assy-Orfs 0x90 | |
| 68 | P930-062012 | Hose Assy-Orfs 0x90 | |
| 68 | 31N4-30310 | Hose Assy-90x90 | |
| 69 | P930-062011 | Hose Assy-Orfs 0x90 | |
| 69 | P930-062010 | Hose Assy-Orfs 0x90 | |
| 69 | P910-062009 | Hose Assy-Orfs 0x0 | |
| 71 | P930-082049 | HOSE ASSY-ORFS 0X90 | |
| 72 | P910-082050 | Hose Assy-Orfs 0x0 | |
| 72 | P910-082047 | Hose Assy-Orfs 0x0 | |
| 77 | X400-062053 | Hose Assy-Synf,Orfs | |
| 78 | S621-014001 | O-RING | |
| 80 | S621-011001 | O-RING | |
| 81 | S621-012001 | O-RING | |
| 82 | P930-087008 | Hose Assy-Orfs 0x90 | |
| 83 | X840-535353 | Tee-R/Type,Swivel,Orfs | |
| 84 | X700-100104 | Plug-Orfs | |
| 85 | 31E3-3187 | Accumulator | |
| 86 | 31N4-22330 | Tee-R/Type,Swivel |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
