Каталог запасных частей к технике: Hyundai R170W-7. MAIN PUMP
5-5
5-5
111
113
116
123
124
124
127
127
141
151
152
153
156
157
211
212
214
251
251
261
262
271
271
312
313
314
401
406
406
466
467
468
490
490
531
532
534
535
548
702
702
710
710
711
717
719
719
724
725
727
728
732
732
774
774
789
792
808
808
824
885
885
886
886
886
901
953
954
981
981
983
5-1
5-2
5-3
5-4
5-6
XJBN-00437
XJBN-00798
XJBN-00799
XJBN-00800
XJBN-00801
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 5-5 | XJBN-00402 | O-Ring | |
| 5-5 | XJBN-00402 | O-Ring | |
| 31N5-15010 | 31N5-15010 | Main Pump | |
| 31N5-15011 | 31N5-15011 | Main Pump | |
| XJBN-00848 | XJBN-00848 | Main Pump Unit | |
| XJBN-00927 | XJBN-00927 | Main Pump Unit | |
| 111 | XJBN-00802 | Shaft(F)-Drive | |
| 113 | XJBN-00803 | Shaft(R)-Drive | |
| 116 | XJBN-00804 | Gear-1st | |
| 123 | XJBN-00429 | Bearing-Roller | |
| 124 | XJBN-00805 | Bearing-Needle | |
| 127 | XJBN-00806 | Spacer-Bearing | |
| 141 | XJBN-00807 | Block-Cylinder | |
| 151 | XJBN-00425 | Piston | |
| 152 | XJBN-00424 | Shoe | |
| 153 | XJBN-00808 | Plate-Set | |
| 156 | XJBN-00422 | Bushing-Spherical | |
| 157 | XJBN-00421 | Spring-Cylinder | |
| 211 | XJBN-00420 | Plate-Shoe | |
| 212 | XJBN-00419 | Plate-Swash | |
| 214 | XJBN-00418 | Bushing-Tilting | |
| 251 | XJBN-00417 | Support | |
| 261 | XJBN-00809 | Cover-Fr | |
| 262 | XJBN-00810 | Cover-Rr | |
| 271 | XJBN-00415 | Casing-Pump | |
| 312 | XJBN-00812 | Block-Valve | |
| 313 | XJBN-00413 | Plate-Valve | |
| 314 | XJBN-00412 | Plate-Valve | |
| 401 | XJBN-00411 | Screw | |
| 406 | XJBN-00410 | Screw | |
| 466 | XJBN-00356 | PLUG | |
| 467 | XJBN-00409 | Plug | |
| 468 | XJBN-00237 | Plug | |
| 490 | XJBN-00032 | PLUG | |
| 531 | XJBN-00815 | Pin-Tilting | |
| 532 | XJBN-00407 | Piston-Servo | |
| 534 | XJBN-00406 | Stopper | |
| 535 | XJBN-00405 | Stopper | |
| 548 | XJBN-00360 | PIN-FEED BACK | |
| 702 | XJBN-00403 | O-RING | |
| 702 | XJBN-00888 | O-Ring | |
| 710 | XJBN-00402 | O-Ring | |
| 711 | XJBN-00878 | O-Ring | |
| 717 | XJBN-00401 | O-Ring | |
| 719 | XJBN-00400 | O-Ring | |
| 724 | XJBN-00361 | O-RING | |
| 725 | XJBN-00362 | O-RING | |
| 727 | XJBN-00233 | O-RING | |
| 728 | XJBN-00097 | O-RING | |
| 732 | XJBN-00879 | O-Ring | |
| 732 | XJBN-00820 | O-RING | |
| 774 | XJBN-00098 | Seal-Oil | |
| 774 | XJBN-00962 | Seal-Oil | |
| 789 | XJBN-00398 | Ring-Back Up | |
| 792 | XJBN-00397 | Ring-Back Up | |
| 808 | XJBN-00396 | Nut | |
| 824 | XJBN-00395 | Ring-Snap | |
| 885 | XJBN-00394 | Pin-Valve Plate | |
| 886 | XJBN-00365 | Pin-Spring | |
| 901 | XJBN-00393 | Bolt-Eye | |
| 953 | XJBN-00105 | Screw-Set | |
| 954 | XJBN-00392 | Screw-Set | |
| 981 | XJBN-00391 | Name Plate | |
| 981 | XJBN-00156 | NAME PLATE | |
| 983 | XJBN-00341 | PIN | |
| Regulator | Regulator | Regulator | |
| 5 | XJBN-00975 | Pto Unit | |
| 5 | XJBN-00926 | Pto Unit | |
| 5 | XJBN-00828 | Pto Assy | |
| 5-1 | XJBN-00160 | Screw-Socket | |
| 5-2 | XJBN-00725 | Socket-Flange | |
| 5-3 | XJBN-00357 | Plug | |
| 5-4 | XJBN-00837 | O-Ring | |
| 5-6 | XJBN-00363 | O-RING | |
| XJBN-00437 | XJBN-00437 | Piston Sub Assy | |
| XJBN-00798 | XJBN-00798 | Cylinder Sub Assy-Rh | |
| XJBN-00799 | XJBN-00799 | Cylinder Sub Assy-Lh | |
| XJBN-00800 | XJBN-00800 | Swash Plate Sub Assy | |
| XJBN-00801 | XJBN-00801 | Tilting Pin Sub Assy |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
