Каталог запасных частей к технике: Hyundai R170W-7. LOWER HYD PIPING 1 (#0979-)
3
3
4
4
4
8
8
9
10
11
12
15
16
17
19
20
21
21
22
23
25
26
26
26
28
31
31
33
33
34
35
37
38
38
40
40
40
40
41
42
42
44
46
47
47
48
48
49
49
49
49
50
50
51
53
55
55
55
56
56
58
58
58
61
62
63
64
64
68
68
69
69
69
69
69
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| LowerHydPiping1 | LowerHydPiping1 | Lower Hyd Piping 1 | |
| 3 | 81E3-0014 | Valve-Locking | |
| 3 | 31Q4-43610 | Valve-Locking | |
| 4 | 31N5-41010 | Pipe Assy | |
| 4 | 31N5-41011 | Pipe Assy | |
| 8 | P703-127315 | Hose Assy-Flg 0x90 | |
| 9 | P913-062020 | Hose Assy-Orfs 0x0 | |
| 10 | P923-042026 | Hose Assy-Orfs 0x45 | |
| 11 | P923-062011 | Hose Assy-Orfs 0x45 | |
| 12 | P923-062013 | Hose Assy-Orfs 0x45 | |
| 15 | P933-122018 | Hose Assy-Orfs 0x90 | |
| 16 | P933-082017 | Hose Assy-Orfs 0x90 | |
| 17 | X500-110011 | CONNECTOR-ORFS | |
| 19 | X500-110013 | CONNECTOR-ORFS | |
| 20 | X500-210005 | Connector-Orfs | |
| 21 | X500-110003 | CONNECTOR-ORFS | |
| 22 | X500-110004 | CONNECTOR-ORFS | |
| 23 | 31N4-41080 | Connector-Orfs | |
| 25 | X520-110001 | ELBOW-90,ORFS | |
| 26 | X520-110002 | ELBOW-90,ORFS | |
| 28 | X850-535300 | Elbow-90,Orfs | |
| 31 | P173-120102 | FLANGE-HYD,SPLIT | |
| 33 | 31EK-70400 | Clamp-Hose | |
| 34 | P392-270000 | Washer-Copper | |
| 35 | S015-080806 | Bolt-Hex | |
| 37 | S017-16050D | BOLT-HEX | |
| 38 | S035-081516 | Bolt-W/Washer | |
| 40 | S109-100306 | BOLT-SOCKET | |
| 41 | S109-120406 | BOLT-SOCKET | |
| 42 | S109-121056 | BOLT-SOCKET | |
| 44 | S411-080006 | WASHER-SPRING | |
| 46 | S411-160006 | WASHER-SPRING | |
| 47 | S621-014001 | O-RING | |
| 48 | S631-011004 | O-RING | |
| 49 | S631-014004 | O-RING | |
| 50 | S631-018004 | O-RING | |
| 51 | S631-024004 | O-RING | |
| 52 | Y161-014001 | O-RING | |
| 53 | Y161-016001 | O-Ring | |
| 55 | Y171-019004 | O-RING | |
| 56 | Y171-024004 | O-RING | |
| 58 | 31N5-41070 | Pipe Assy | |
| 58 | 31N5-41071 | Pipe Assy | |
| 61 | X500-220007 | Connector-Orfs | |
| 62 | P392-180000 | Washer-Copper | |
| 63 | P174-160115 | FLANGE-SPLIT | |
| 64 | S621-018001 | O-RING | |
| 68 | S621-011001 | O-RING | |
| 69 | S621-012001 | O-RING |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
