Каталог запасных частей к технике: Hyundai R170W-7. FRONT AXLE OUTPUT GROUP (-#0978)
10
30
40
40
40
40
40
40
40
40
40
40
40
40
50
80
90
120
130
130
150
160
200
210
210
214
230
232
238
248
256
258
270
270
270
280
290
300
320
340
340
350
350
360
370
390
400
410
420
420
430
480
480
480
480
480
480
480
490
500
510
540
570
620
630
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| Axle-Front | Axle-Front | Axle-Front | |
| 10 | 0750-110-156 | Seal-Shaft | |
| 30 | 0735-370-269 | Bearing-Roller | |
| 40 | 0730-161-827 | Ring | |
| 40 | 0730-161-828 | Ring | |
| 40 | 0730-161-829 | Ring | |
| 40 | 0730-161-830 | Ring | |
| 40 | 0730-161-831 | Ring | |
| 40 | 0730-161-832 | Ring | |
| 40 | 0730-161-833 | Ring | |
| 40 | 0730-162-560 | Ring | |
| 40 | 0730-162-561 | Ring | |
| 40 | 0730-162-562 | Ring | |
| 40 | 0730-162-563 | Ring | |
| 40 | 0730-162-564 | Ring | |
| 50 | 0750-117-167 | Bearing-Roller | |
| 80 | 4472-373-227 | Hub | |
| 90 | 0634-304-060 | O-Ring | |
| 120 | 0631-405-028 | Plug | |
| 130 | 0634-313-188 | O-Ring | |
| 150 | 0730-502-079 | Retainer Ring | |
| 160 | 4472-319-266 | Gear-Ring | |
| 200 | 4472-319-220 | Piston | |
| 210 | 0734-317-249 | U-Ring | |
| 214 | 0501-314-506 | Ring | |
| 230 | 0501-314-461 | Ring-Support | |
| 232 | 4472-319-102 | Shim-Support | |
| 238 | 0632-041-095 | Spring-Compr | |
| 248 | 0637-011-591 | Nut-Locking | |
| 256 | 0636-104-158 | Screw-Cap | |
| 258 | 4472-320-071 | Sleeve-Spring | |
| 270 | 4462-305-079 | Disc-O/Clutch | |
| 270 | 4462-305-081 | Disc-O/Clutch | |
| 270 | 4462-305-080 | Disc-O/Clutch | |
| 280 | 0501-314-381 | Disc-I/Clutch | |
| 290 | 4462-305-050 | Shim-End | |
| 300 | 0630-502-187 | Retainer Ring | |
| 320 | 0730-106-288 | Washer-Thrust | |
| 340 | 4472-319-157 | Shaft-Sun Gear | |
| 340 | 4472-377-046 | Shaft-Sun Gear | |
| 350 | 4472-377-037 | Carrier-Disc | |
| 350 | 4472-377-047 | Carrier-Disc | |
| 360 | 0630-531-057 | Ring-Retainer | |
| 370 | 0630-502-075 | Retainer Ring | |
| 390 | 4472-377-035 | Carrier-Planet | |
| 400 | 4472-364-006 | Gear-Planet | |
| 410 | 0735-455-281 | Bearing-Roller | |
| 420 | 0501-309-954 | Ring-Angle | |
| 430 | 0630-501-029 | Retainer Ring | |
| 480 | 0730-104-159 | Washer-Thrust | |
| 480 | 0730-104-160 | Washer-Thrust | |
| 480 | 0730-105-126 | Washer-Thrust | |
| 480 | 0730-105-385 | Washer-Thrust | |
| 480 | 0730-105-400 | Washer-Thrust | |
| 480 | 0730-105-401 | Washer-Thrust | |
| 480 | 0730-105-800 | Washer-Thrust | |
| 490 | 0634-303-485 | O-Ring | |
| 500 | 0736-302-046 | Plug-Screw | |
| 510 | 0636-102-053 | Screw-Cap | |
| 540 | 4472-319-214 | Bolt-Wheel | |
| 570 | 0637-018-031 | Nut-Wheel | |
| 620 | 0636-302-003 | Plug-Screw | |
| 630 | 0634-306-523 | O-Ring |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
