Каталог запасных частей к технике: Hyundai R16-9. PILOT HYD PIPING 3 (SOLENOID)
2
6
10
11
12
14
17
21
23
25
29
30
32
33
34
35
37
42
42
42
42
42
42
43
43
45
47
48
48
49
49
54
55
55
55
55
55
55
55
55
55
55
55
55
55
55
57
57
57
57
57
57
57
57
58
58
58
58
58
58
60
61
62
63
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 2 | 31MJ-20040 | 2-Cartridge Valve | |
| 6 | 31E3-3187 | Accumulator | |
| 10 | 31LB-40340 | Tee | |
| 11 | 31EK-11130 | COUPLING-SCREW | |
| 12 | X511-106524 | Connector-Long, Orfs | |
| 14 | 31MJ-20360 | Bracket | |
| 17 | X400-042019 | Hose Assy-Synf, Orfs | |
| 21 | X410-062008 | Hose Assy-Orfs 0x45 | |
| 23 | X420-042006 | Hose Assy-Orfs 0x90 | |
| 25 | X420-042008 | HOSE ASSY-ORFS 0X90 | |
| 29 | X420-042013 | Hose Assy-Orfs 0x90 | |
| 30 | X420-042018 | Hose Assy-Orfs 0x90 | |
| 32 | X420-042021 | HOSE ASSY-ORFS 0X90 | |
| 33 | X420-042023 | Hose Assy-Orfs 0x90 | |
| 34 | X420-062012 | Hose Assy-Orfs 0x90 | |
| 35 | X440-062006 | Hose Assy-Orfs 90x90 | |
| 37 | X410-042013 | Hose Assy-Orfs 0x45 | |
| 42 | X500-110001 | CONNECTOR-ORFS | |
| 43 | X500-110002 | CONNECTOR-ORFS | |
| 45 | X520-110001 | ELBOW-90,ORFS | |
| 46 | 31M9-30230 | Connector-Bulkhead | |
| 46 | 31M9-30250 | Connector | |
| 47 | 31N6-25110 | ELBOW-90,LONG | |
| 48 | X820-045151 | TEE-R/TYPE,ORFS | |
| 49 | X820-065151 | Tee-R/Type, Orfs | |
| 54 | P220-110103 | PLUG-HEX | |
| 55 | S621-011001 | O-RING | |
| 57 | S631-011004 | O-RING | |
| 58 | S631-014004 | O-RING | |
| 60 | P391-080000 | Washer-Copper | |
| 61 | S037-122026 | BOLT-W/WASHER | |
| 62 | S037-102026 | BOLT-W/WASHER | |
| 63 | S035-082526 | BOLT-W/WASHER |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
